TARGET HD 6
Operator's manual
GB
Read these instructions carefully and
make sure you understand them before
using HD 6.
Manual de
E
Instrucciones
Antes de utilizar HD 6 lea bien el
manual de instrucciones hasta
comprender su contenido.
Bedienungsanweisung
D
Lesen Sie die Bedienungsanweisung
sorgfältig durch und machen Sie sich
mit dem Inhalt vertraut, bevor Sie
HD 6 benutzen.
Manuel d'utilisation
F
Lire attentivement et bien assimiler le
manuel d'utilisation avant de se servir
HD 6.

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Target HD6

  • Seite 1 TARGET HD 6 Operator’s manual Read these instructions carefully and make sure you understand them before using HD 6. Manual de Instrucciones Antes de utilizar HD 6 lea bien el manual de instrucciones hasta comprender su contenido. Bedienungsanweisung Lesen Sie die Bedienungsanweisung sorgfältig durch und machen Sie sich...
  • Seite 2 Read, understand and follow all Always use eye and ear Read all the operating instructions warnings and instructions in these protectors when using the before using or carrying out service procedures on the machine. operating instructions and on the machine. machine.
  • Seite 3 WARNING! Under no circumstances may the machines be modified from the original designs without the manufacturer’s approval. Unapproved modifications can result in serious personal injury or even death. WARNING! These machines can be dangerous if they are used improperly or without due care and such use can lead to serious accidents or, in the worst case, fatal accidents.

  • Seite 4: Inhaltsverzeichnis

    Contents Safety Instructions __________________________________________________________________ 6 Presentation ______________________________________________________________________ 10 Technical Data ____________________________________________________________________ 12 What Is What? ____________________________________________________________________ 13 Operation ________________________________________________________________________ 14 Care and Maintenance ______________________________________________________________ 19 EU Declaration of Conformity to Directive _______________________________________________ 22 Índice Instrucciones de seguridad ___________________________________________________________ 7 Presentación _____________________________________________________________________ 10 Datos técnicos ____________________________________________________________________ 12 Componentes de la máquina _________________________________________________________ 13 Manejo __________________________________________________________________________ 14...

  • Seite 5: Safety Instructions

    You can, however, prevent accidents yourself by always using common sense. During the design and manufacture of Target products, great importance is placed on safety, as well as effectiveness and ease of use. This machine has been designed and is intended to be used for drilling in concrete, brick and various stone materials. All other use is improper.

  • Seite 6: Instrucciones De Seguridad

    También es posible prevenir accidentes utilizando el sentido común. En el diseño y fabricación de los productos Target se ha puesto un gran énfasis en la seguridad, además de la efectividad y la facilidad de manejo.

  • Seite 7: Sicherheitsanweisungen

    Darstellung aller möglichen Gefahrensituationen enthalten, die bei der Benutzung des Geräts aufkommen können. Wer jedoch stets den gesunden Menschenverstand einsetzt, kann Unfällen selbst vorbeugen. Bei der Konstruktion und Herstellung von Target Produkten wurde neben der Leistungsfähigkeit und Benutzerfreundlichkeit größtes Gewicht auf die Sicherheit gelegt.

  • Seite 8: Consignes De Sécurité

    Lors de la conception et de la fabrication des produits Target, un soin particulier a été apporté à la sécurité des machines, outre leur efficacité et leur simplicité d’utilisation.

  • Seite 9: Presentation

    Fig. 1 Presentation HD 6 are an electric handheld drill, intended for drilling concrete, brick and various stone materials. It is designed for The machines are equipped with the patented functions drilling in confined spaces and are very easy to assemble. Softstart™, Smartstart™, and Elgard™.
  • Seite 10 ENG Smartstart™ If the motor is overloaded, the overload protection makes If the Smartstart™ button is pressed directly after the switch the motor pulsate. By backing off on the feed pressure, the has been pressed, the speed of the core bits is reduced motor will again operate in a normal fashion.

  • Seite 11: Technical Data

    Technical data (GB, US, CAN) Spindle Thread ______________________ G 1/2" Water Connection (HD 6) ______________ G 1/4" Rated Voltage ____________________________ 100-120V Weight (HD 6) _______________________ 5.2 kg Rated Power _____________________________ 1800 W Rated Current ____________________________ 15 A Max Drill ø with Rig ________________________ 130 mm(5") Max Drill ø, Hand-held ______________________ 60 mm (2 1/2") Stand Sound Pressure Level ______________________ 86 dB A, 86 dB C...

  • Seite 12: What Is What

    Fig. 4 What is What? a. Drill spindle f. Button for locking the switch b. Cooling system connector g. Spirit level (3 pcs) c. Screws holding together the gearbox and the h. Inspection hatches motor (4 screws) Gear knob d. Smartstart™ Leakage hole e.

  • Seite 13: Operation

    Fig. 5 Operation • The switch is not sticking. • Always use a Ground Fault Interrupter when connecting WARNING! to power. Check that the output voltage corresponds Failure to follow the operating instructions may with the voltage marked on the plate on the top of the cause serious personal injury.
  • Seite 14 Fig. 7 Before Starting (cont) Using the Machine • The right clothes and protective equipment are in use. Consider the following when using the machine: • When using Smartstart™, the machine has a very low power output. As a result, normal drilling cannot be Starting the Machine carried out with this function.
  • Seite 15 WARNING! Only use gear 2 and 3 for handheld drilling. Gear 1 has som much torque that the drill is harder to control if the drill bit gets stuck. ENG Using the Machine (cont) Hand held drilling: • Keep your hands at a safe distance from the drill •...
  • Seite 16 When drilling outdoors: NOTE! • Always use extension cables that are approved for If gears are changed while the unit is still rotating, there is outdoor use. a high likelihood for damages to the gearbox. When drilling in roofs and the like: •...
  • Seite 17 Fig. 8 Changing the Drill Bit In order to change the drill bit, do as follows: 4. Apply water-resistant grease to the thread of the new drill bit. 1. Pull out the plug. 5. Attach the drill bit using the open-end spanners (Fig. 8). 2.

  • Seite 18: Care And Maintenance

    Fig. 9 Electricity Supply Care and Maintenance Inspect all cables, extension cables and outlets regularly in order to The lifetimes of the HD 6 can be extended considerably if they are detect any damage or faults early. Damaged cables must be replaced before next use.
  • Seite 19 Fig. 10 Fig. 11 Changing the Gearbox Oil The oil in the gearbox shall be changed after every 400 3. Remove the four screws (c in Fig. 10) that hold together hours of operation. Do as follows: the motor and the gearbox. 4.
  • Seite 20 Fig. 12 Fig. 13 Changing the Carbon Brushes 5. Pull the carbon brush out from the holder (III in Fig. 13). The carbon brushes must be removed and inspected 6. Insert the new carbon brush. Check that is slips easily regularly: Weekly if the machine is used daily or at longer into the holder.

  • Seite 21: Eu Declaration Of Conformity To Directive

    531 07 99-00-1 2003W19...
