Operating Controls
1 Nosepiece
2 Outer sleeve
3 Eye hook
4 Mandrel collector
5 Nosepiece magazine
6 LED overload
7 On/Off switch
8 Battery pack
9 Hand-guard
Not all of the accessories illustrated or described are included
as standard delivery.
Intended Use
The tool is intended for the setting of rivets.
For damage caused by usage other then intended,
the user is responsible.
Battery Pack
Use only the battery pack intended for this
power tool.
Convince yourself before using that the battery pack
is securely seated in the machine.
The battery pack must be charged before initial op-
eration.
To operate the charger and for details on the charg-
ing process please refer to "Charger" in the en-
closed instructions.
With proper use, the battery pack can be recharged
up to 1000 times.
A new battery pack will not reach its full capacity un-
til after approx. 5 charging- and discharging cycles.
This also applies for battery packs, which have not
been used for extended periods.
Never run down the battery pack completely.
An extended service life expectancy is reached
when a load is put on the battery pack regularly and
it is recharged afterwards.
When not storing the battery pack in the recharger,
ensure to recharge it from time to time.
A considerably reduced operating time despite
charging indicates, that the battery pack is used up
and must be replaced.
10
Initial Operation
Changing the nosepiece
Remove the cover of the nosepiece magazine
A
(which is a wrench, size 12 mm) and select the fitting
nosepiece.
Always use the right sized nosepiece to
avoid faulty riveting.
B Unscrew the nosepiece in use.
Press the On/Off switch 7, while tightly screw-
C
ing in the nosepiece 1 with the wrench.
Reinsert currently not used nosepieces into the nose-
piece magazine 5 and close the magazine with the
cover.
Riveting
Insert a rivet into the nosepiece 1. Enter the rivet
head vertically into the rivet hole of the workpiece
and press against it.
Press the On/Off switch 7. Release the switch after
the rivet has been set.
The spent mandrel falls into the mandrel collector or
out of the nosepiece towards the front.
The mandrel collector 4 must be emptied in regular
intervals.
Overload protection
In case of overload, the riveting process is interrupt-
ed and the LED 6 lights up.
Release the On/Off switch 7.
Maintenance and Cleaning
The unit and the battery pack are free of mainte-
nance.
If the machine should happen to fail despite the care
taken in manufacture and testing, repair should be
carried out by an authorized customer services
agent for Würth power tools.
In all correspondence and spare parts orders,
please always include the 7-digit order number giv-
en on the nameplate of the machine.
