Quick reference
30.3307.02 Wind sensor
WeatherHub Sensor
This sensor is a component of the „WeatherHub" system for measuring wind speed and wind direction, it can
be used with this system only. To use the sensor you need an installed WeatherHub gateway.
Before you use it:
Please be sure to read this short-instruction manual carefully.
Following the instruction manual for use will prevent damage to the device and loss of your statutory rights
arising from defects due to incorrect use.
We shall not be liable for any damage occurring as a result of not following these instructions. Likewise, we take
no responsibility for any incorrect readings and for any consequences which may result from them.
Please take particular note of the safety advice!
Please look after this manual for future reference.
For your safety:
•
The product is exclusively intended for the field of application described above. The product should only
be used as described within these instructions.
•
Unauthorised repairs, modifications or changes to the product are prohibited.
Caution!
Risk of injury:
Keep this instrument out of reach of children.
Important information on product safety!
•
Do not place your device near extreme temperatures, vibrations or shocks. Caution: The wind vane and
wind cups are very delicate. Do not drop the device and avoid collisions.
•
Clean the instrument with a soft damp cloth. Do not use solvents or scouring agents. For a good
function keep the solar panel always clean. Do not submerge the unit in water.
•
Make sure that the wind vane and wind cups can spin freely and are free from dirt, debris or spider
webs
Sensor set up
Remove the protection seal from the solar panel of the wind sensor. Activate the wind sensor with the included
tool. Please carefully insert the tool in the hole marked with an arrow and press the inside button.
Positioning
The wind sensor must be installed with the front of the sensor (the solar panel) facing true south, or the reported
wind direction will not be accurate. Mount within the wireless range of the WeatherHub gateway and ideally on
the same side of the house. Secure the main unit to the shaft of the mast holder. Use the right-angle adaptor if
the wind sensor will be mounted on a horizontal mast or surface.
Fasten the wind sensor to a suitable mast using the two U-bolts, washers and nuts included. Note: Mount the
wind sensor onto a mast so the wind can reach the sensor unobstructed from all directions for an accurate
reading. The ideal mast is between 16 mm and 33mm in diameter. The wind sensor does not have replaceable
batteries; it consumes solar power and charges the internal battery pack automatically. Please consider when
choosing a location that the solar panel gets enough sunlight and is not covered by objects to guarantee a long-
term sufficient power supply.
Add Sensor
Open the app, dashboard is displayed. Tap „Add new sensor" and scan the QR code on the bottom of the wind
sensor. A copy of the sensor code is attached. Then set a name for the sensor.
Specifications
Wind speed and gust:
Measuring range:
0.3 ... 50 m/s
Resolution:
0.1 m/s
Measuring range:
+/- 1m/s < 8m/s, +/-10% > 8m/s (wind speed only)
Wind directions:
16 (resolution 22.5°)
Transmission to gateway:
every 7 minutes
Frequency:
868.3 MHz
Transmission range:
100m (open area)
Power supply:
Solar panel with integrated rechargeable battery
(2 x Micro LR03 AAA alkaline)
Waste disposal
This product has been manufactured using high-grade materials and components which can be recycled and
reused.
Never throw flat batteries and rechargeable batteries in household waste.
As a consumer, you are legally required to take them to your retail store or to appropriate
collection sites according to national or local regulations in order to protect the environment.
The symbols for the heavy metals contained are: Cd=cadmium, Hg=mercury, Pb=lead
This instrument is labelled in accordance with the EU Waste Electrical and Electronic Equipment
Directive (WEEE). Please do not dispose of this product with other household waste. The user is
obligated to take end-of-life devices to a designated collection point for the disposal of
electrical and electronic equipment, in order to ensure environmentally-compatible disposal.
Declaration of conformity
Herewith we declare, that this wireless transmission device does comply with the essentials requirements of
R&TTE Directive 1999/5/EC. A copy of the signed and dated Declaration of Conformity is available on request
via info@tfa-dostmann.de.
More information and detailed instructions can be found in the app at "Info" or on
www.tfa-dostmann.de/weatherhub.
TFA Dostmann GmbH & Co. KG, Zum Ottersberg 12,
D-97877 Wertheim, www.tfa-dostmann.de
