Operation

Do not reach into the input slot.
Do not insert any paper clips or other metallic objects into the input slot.
People with long hair must maintain and adequate distance to the input slot.
Keep ties, scarves, loose clothing and long necklaces or bracelets away from the
input slot.
Never use any spray bottles/cans in the immediate vicinity of the product.
The top of the device gets hot during use. Do not touch.
Do not use this product with cardboard film carriers. This can lead to jamming or
damage to the product.
Use only suitable hot laminating pouches.
Never insert a pouch into the input slot with the open side first.
Do not laminate any heat-sensitive materials, such as thermal paper.
The objects to be laminated must be completely dry, so that a satisfactory result is
achieved.
Do not cut laminating pouches to the required size, as the cut edges can lead to
jamming.
Be careful when removing hot laminated objects from the output slot.
Make sure, that the operating switch is in the Off position before you connect the
device to the power outlet.
Wait 15 seconds between every laminating process.
Never use the laminator for longer than one hour in continuous operation.
After you have switched the product off, allow it to cool down for 30 minutes before
you switch it on again.
• Connect the power plug to an appropriate power outlet.
• Select a suitable pouch (80 or 125 micron) for the object to be laminated.
• Depending on the film thickness, set the operating switch to the position 80Mic or 125Mic.
The indicator POWER lights up red and thereby indicates, that the product has been switched
on.
• The preheating of the product takes approx. 3 – 5 minutes. After the preheating the indicator
READY lights up green and thereby indicates, that the product is ready for laminating.
• Place the object to be laminated into the pouch alongside the sealed edge and leave
3 – 5 mm free to the edge of the pouch.
• Insert the pouch into the input slot with the closed edge first, until it is captured by the rollers.
Make sure, that the pouch is aligned to the markings above the input slot. The pouch travels
through the product and is output at the back.
• Switch the product off after use (switch to position Off) and pull out the mains plug.
• Before you stow the product away (e.g. in a cabinet), allow it to cool down for approx. 10 –
15 minutes, until it has reached room temperature.
After 60 minutes continuous operation the READY indicator goes out and the
POWER indicator flashes. The heating process is aborted. In this case, abort the
laminating process. The POWER indicator flashes for altogether 5 minutes and then
goes out. The motor is shut down.
In this case, switch the product off, disconnect the mains plug and allow the product
to rest for 30 minutes before you use it again.

Troubleshooting

• If an object has jammed in the product, switch it off and pull out the mains plug. Then press
the release switch down and hold it in this position, while you carefully pull out the jammed
object.
• If the product cannot be switched on, check the following points:
- Check, whether the mains plug is plugged into a power outlet.
- Check, whether the product has been switched on.
- Check, whether there is a paper jam.
- It can also be possible, that the motor is overheated and the thermal circuit breaker has
tripped. In this case allow the product to cool down and try again after 30 minutes.

Cleaning and care

• Disconnect the product from the mains supply before cleaning. Allow the product to cool
down, until it has reached room temperature.
• Under no circumstances use aggressive cleanings agents, cleaning alcohol or other chemical
solutions since these can penetrate the housing or impair functionality.
• Clean the product with a dry, fibre-free cloth.
• You can easily remove dust with a long-haired, soft and clean brush.
• Clean the rollers regularly. To do this, fold a sheet of A3 paper (item no. 1486147) or a sheet
of A4 paper (item no. 1486148) and insert it into the input slot with the folded side first. The
residues on the rollers remain stuck to the paper. Repeat this procedure several times.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accordance
with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the
environment.

Technical data

Operating voltage ......................... 220 – 240 V/AC, 50 Hz
Format .......................................... A3 and smaller (item no. 1486147)
A4 and smaller (item no. 1486148)
Power consumption ...................... 350 W (item no. 1486147)
300 W (item no. 1486148)
Lamination speed ......................... 300 mm/min
Lamination thickness .................... max. 0.6 mm
Film thickness ............................... 80 and 125 micron
Warm-up time ............................... 3 – 5 min
Number of reels ............................ 2
Cable length ................................. 1.5 m
Protection class ............................ II
Operating/storage conditions ........ +10 to +35 °C, 20 - 75 % RH
Dimensions (W x H x D) ............... 480 x 80 x 167 mm (item no. 1486147)
380 x 80 x 167 mm (item no. 1486148)
Weight .......................................... 2.35 kg (item no. 1486147)
1.9 kg (item no. 1486148)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represents the technical status at the time of printing.
Copyright 2016 by Conrad Electronic SE. *1486147_8_V2_0816_02_IPL_m_en
