Handlamp Akku LED 5x3W
2
Operation manual
The rechargeable lamp typ G40R is a modern working and inspection lamp, which is for
varied uses and applications. So it is suitable for among other things:
• Inspection lamp for maintenance purposes
• Work light
• Private use
This lamp (see label) comply with the EU Guidelines of the Low Voltage Directive 2014/35/
EU, the EMC Directive 2014/30/EU and the Artificial Optical Radiation Directive 2006/25/
EG and is manufactured with compliance Directive 2011/65/EU RoHS.
Technical data battery lamp:
Housing material: Plastic shockproof gummed, aluminium lamp head black.
Weight:
850g including battery
Int. protection:
IP 65
LED:
LED 5x3W 900lm
Battery/voltage:
Battery Lithium-Ion 7,4VDC 4400mAh
Charging /
charging time:
Connect the charger plug with the charging socket of the lamp. Then
connect charger to socket 230VAC or car socket 12/24VDC. Charging
time full loading (from empty to 100% capacity) approx. 5h. Light
indicator LED1 green = 100%.
Charger:
230VAC 50/60Hz IP20, Car 12/24VDC/8,4VDC, optional accessory
5-way charger.
Light function:
100% / 50% / blinking function (multifunction switch).
Lighting time:
mode 100% approx. 5h, mode 50% approx. 10h
Capacity display: LED2 green >65%, yellow 25-65%, red 10-25%, red blinking <10%,
from yellow to red lamp blinks 2 times, from red to red blinking lamp
blinks 2 times.
Temperature range: -20°C to +45°C (charge/storage +10°C to +30°C)
Additional
features:
Swiveling lamp head
Swiveling handle 180°
Base with magnet 4x50N
USB socket 5VDC 2A (for example to use as power pack for smart-
phones)
Operation:
Before the first use, please charge the lamp (LED indicator green).
Use only original charger.
Storage:
For long time storage, only store lamp fully charged.
Recharge lamp every 4 months.
Cleaning:
If dirty, clean the lamp with cleaning tissue or soft brush.
Do not use abrasives or solvents.
Disposal:
The product has to be supplied to a suitable landfill or
to a recycling process in accordance to the local and
national regulations.
ATTENTION:
The focused light beam can damage the eye under
special circumstances. Do not look without special
protective measure from close range directly at the LED.
As a precaution, we recommend safety glasses with
tinted lenses.
To assure the product safety and functional reliability, all kind of repairs or
maintenance (in accordance to national regulations) must be done by profes-
sionals and only by using original spareparts.
Periodic inspections are according to the current national
guidelines.
No guarantee for technical changes or printing errors.
PC Electric GmbH
Diesseits 145 | AT-4973 St. Martin/Innkreis
Phone +43 (0) 77 51/61 220
Fax +43 (0) 77 51/69 69
eMail: office@pcelectric.at
charging
indicator LED1
Charger
230 VAC, 50/60 Hz, IP20
Car charger
12–24V DC
Art.450020
swiveling lamp
head
Power-LED 5x3W
Multifunction
switch
capacity indicator
LED2
USB socket
5VDC 2A
4x magnet 50N
120
swiveling handle 180°
charging socket
90
115
