DIRECTIONS
1. Position the laser light in such a way that there are no obstacles
between the unit and the area you want to illuminate.
2. Insert the ground peg at the desired location.
Make sure it is inserted far enough into the ground.
3. Attach the laser to the ground peg. Make sure it is firmly attached
to the peg.
4. Adjust the projection angle using the adjustment screw on the side
of the laser unit. Once you are satisfied, tighten the screw (do not
overtighten).
5. Connect the cord and plug the laser light into the electrical outlet.
6. Turn the laser light on by pressing the black button on the back of
the device.
CLICK THE BUTTON TO SWITCH BETWEEN THE 5 DIFFERENT OPTIONS:
1: Red and green steady light
2: Red and green flashing light
3: Steady green light
4: Steady red light
5: OFF
TECHNICAL DATA
Laser
Class 3R
Operating
-20° C – +40 ° C
temperature
Use
Indoor/Outdoor
Transformer
Input: 100–240V, 50–60Hz
Output: DC 5.0V/1.5A
RIGHT OF COMPLAINT
By law the product must be returned to the place of purchase along with the original
receipt in the event of a complaint. The user is liable for any damage to the product that
is caused by not using the product for its intended purpose or by not following this user
manual correctly. The right of complaint will not apply in these instances.
INFORMATION ABOUT HAZARDOUS WASTE
Used products should be handled separately from
household waste. They should be taken for recycling in
accordance with local rules for waste management.
Power
5W
Safety class
IP44
Coverage
A distance of 10 m provides
coverage of approximately 15x15m
Screw
Adjust
angle
Mounting
connector
Ground peg
3
