eNgLISh
1. Introduction
1.1. Scope of delivery
• 1x external 2.5" hard drive, USB 3.0, in a compact housing
• 1x warranty card
• 1x USB 3.0 cable
• 1x operating instructions
Please contact us immediately if any of the above items are missing or damaged.
1.2. System requirements
• When connected to the existing USB 2.0 slot up to 10 % faster than conventional
USB 2.0 data storage medium.
• Full utilization of speed with USB 3.0 adapters from CnMemory
The compatibility to USB 2.0 devices will still be guaranteed.
Express Card USB 3.0 Express Card USB 3.0
Item No 68751 Item No 68753
• Intel Pentium II 350 MHz processor or Apple G3 processor or higher /
min. 512 MB RAM / USB port 3.0 recommended.
• Compatible with Windows 2000, XP, Vista or higher and Mac OS 10.0 or higher.
Compatible with Mac by simple reformatting (FAT 32).
2. Installing the hardware
• Switch on your computer and wait until it has fully initialised the operating system.
• Plug the smaller end of the supplied USB cable into the back of your USB hard drive
(Fig. 1).
• Next, plug the other end of the cable (when Y-USB cable is provided use both plugs)
in your computer's USB port(s) (Fig. 2).
• The hardware wizard icon will first appear, followed by the icon for safely removing
the hardware.
.
®
PCI-Express Card USB 3.0
Item No 68771
• Check the LED function display for your hard drive; this indicates the operational
readiness.
• No drivers need to be installed for operating systems Windows 2000 or higher
(Plug & Play).
• A separate power supply via a power supply unit is optional, but not necessary.
Fig. 1 (Fig. similar)
3. Using the external USB hard drive
To transfer data, you can access your external USB hard drive via Windows Explorer
or your workstation. You can then save, move or delete your data as usual.
During the data transfer process, the LED function display will flash (not the case for
all models).
Never disconnect the USB hard drive while transferring data, as this may result
in lost or corrupted data.
Note that for Windows 2000, XP, Vista and higher, you need to choose the "Safely
Remove Hardware" icon in the taskbar (next to your computer's time display) to
dismount the USB hard drive. Failure to do so may also result in data on the hard
drive being lost or corrupted.
4. Safety instructions
• Do not cover the hard drive during operation (may cause overheating).
• Avoid temperature fluctuations (winter: condensation / summer: exposure to sunlight).
• Avoid magnetic fields.
5. Technical support
If you experience any problems, please contact us with the following information to
hand:
• Your computer's operating system and configuration
• Names of any additional peripheral devices you are using
• (Error) messages appearing on the screen
• Name of the software you were using when the error occurred
• Steps you have taken to resolve the problem
• Your customer number (if available)
• Purchase date and barcode-number of your hard drive
Fig. 2 (Fig. similar)
