4. ASCII Remote Protocol
RS232 Protocol
19200 Baud
8 DataBit
No Parity
1 Stopbit
IP Protocol: IPV4
TCP/IP xxx.xxx.xxx.xxx
Every CMD start
ASCII-Escape
with
then the Tuner-ID Is ASCI 0
the CMD
....
and stop with
ASCII – Carriage
Return
For Example
Get Version:
No. Command
To ProTUNE HD
1
Get IsBusy
ESC,0,F,B,?,CR
2
Get Time
ESC,0,F,T,?,CR
3
Set Time
ESC,0,F,T,HZ,HE,
MZ,ME,SZ,SE,CR
4
Get Date
ESC,0,F,D,?,CR
5
Set Date
ESC,0,F,D,DZ,DE,
MZ,ME,YZ,YE,CR
6
Get DispLight
ESC,0,F,L,?,CR
7
Set DispLight
ESC,0,F,L,VZ,VE,
CR
8
Get DispContr
ESC,0,F,C,?,CR
9
Set DispContr
ESC,0,F,C,VZ,VE,
CR
10
Get Version
ESC,0,F,V,?,CR
11
GetLastIrKey
ESC,0,F,I,?,CR
12
Set IrKey
ESC,0,F,I,KEY,CR
13
GetKeyLock
ESC,0,F,K,?,CR
14
SetKeyLock
ESC,0,F,K,STATE
,CR
15
GetPowerOn
ESC,0,F,S,?,CR
16
SetPowerOn
ESC,0,F,S,STATE
,CR
16
SetSleepTimer
ESC,0,F,E,VALUE
,CR
17
SetFactoryReset
ESC,0,F,F,9,CR
18
GetTunerType
ESC,0,F,G,?,CR
Defaultport
10001
ESC = 0x1b =27
0 = 0x30 = 48
CR = 0xd = 13
‚ESC'0FV? ‚CR'
To ProTUNE HD
‚ESC'0FV01.00'CR'
From ProTUNE HD
From ProTUNE HD
ESC,0,F,B,State,CR State = 1 if
Busy
when:
ESC,0,F,T,HZ,HE,MZ,
HHMMSS
ME,SZ,SE,CR
ESC,0,F,T,CR
ESC,0,F,D,DZ,DE,MZ
DDMMYY
,ME,YZ,YE,CR
ESC,0,F,D,CR
ESC,0,F,L,VZ,VE,CR
ESC,0,F,L,CR
0 - 31
ESC,0,F,C,VZ,VE,CR
ESC,0,F,C,CR
0 - 7
ESC,0,F,V,MZ,ME,.,M
01.00
Z,ME,CR
ESC,0,F,I,KEY,CR
See IrTable
ESC,0,F,I,CR
ESC,0,F,K,STATE,CR State 0 =
UNLOCK
ESC,0,F,K,CR
State 1 =
LOCK
ESC,0,F,S,STATE,CR State 0 =
Power Off
ESC,0,F,S,CR
State 1 =
Power On
ESC,0,F,E,CR
Value = 0 off, 1
10, 2 30, 3 60,
4 90, 5 120
Minutes
ESC,0,F,F,CR
FactoryReset
ESC,0,F,G,V,CR
Value : 1 =
Satelite, 2 =
Cable, 3 =
Terrestrial
Ask for Version
Get Version
Initializing
Upgrade host
OTA Upgrade
Search Program
USB Upgrade
01.00
