BURNER ASSEMBLY
The burner hangs loose in the slot of the stand. Choose an accessible place for you to install the controls in the preparation of the
barbecue.
Ü
figure A
Ü
figure B
Ü
figure C
CONNECTION GAS BOTTLE
The oneQ gasbarbecue is suitable for both propane and propane / butane (gas). We advise you to use standard 5 or 10 kg cylinders.
Use a regulator that matches the pressure indicated on the date plate.
Ü
figure D/E
OPERATION AND FIRST USE
The (gas) burner is fully assembled and properly adjusted at the delivery by the manufacturer. In the first use of the barbecue it is
important that you completely remove all packaging materials.
Before you use the grid or plate for the first time, you should wash it in hot water with mild detergent, rinse and dry it. After that, put it
on the (gas)burner.
Ü
figure F
Depending on the type of gas and gas pressure the oneQ barbecue has a load of 6,7-8,0 kW. The burnerpower
can be adjusted with the knob. Do not fully heat up the barbecue when using a Plate and/or Top or Hood (keep
the knob in the downward position at all times).
Ü
figure G

TROUBLESHOOTING

Failures
Burner will not ignite
or does not burn
completely.
Ü
figure H
Is the problem remains unresolved then contact your oneQ supplier.
CLEANING & MAINTENANCE
We recommend cleaning the grills, Teppan Yaki plate (optional), baffle and burner after each use. Check all areas where oil, grease or
food residue may accumulate, then you keep all parts in optimal condition.
SERVICE, WARRANTY AND CERTIFICATIONS
If you have problems with your oneQ flame or if you want to order (reserve) parts, contact your dealer or see www.one-q.com, where
you find an extensive customer service section.
the oneQ barbecue measures up to the NEN-EN 498 standard for barbecues and is certified by the world-renowned KIWA GASTEC
testing station for gas appliances.
ONEQ B.V.
Place the drip tray in the appropriate/suitable hole of the plateau.
Carefuly release the (gas)burner in the slot of the stand. Place the points of the 2 flame distributors into
the holes of the burner.
Put the grill (or the optional Teppan Yaki plate) over the edge of the burner. Then place the control knob
on the gas tap and insert the battery.
Bend the four notches on the cross up. Place the cylinder on the cross, with the bottom of the bottle
around the ridges. Then attach the hose to the gas tap by turning/ tighten the nut.
Press the control knob and turn it to the left to the ignition position until the burners are burning
completely.
The grill and Teppan Yaki plate have a high-and low-temperature zone. This distribution offers a
convenient range while preparing food.
Possible Cause
- ignitionpin dirty
- cylinder (almost) empty
- hose kinked
- restriction air intake manifold
- burner tubes are wet (after cleaning)
- Defective pressure regulator
The 2 air intakes at the bottom of the manifold should have an unobstructed air input. If there is dirt in it
should remove it.
Solution
clean pin
replace cylinder
remove kink
release air intake
leave to dry
replace
-15-
