Lindy 43181 Benutzerhandbuch

USB 3.0 Notebook Docking Station
HDMI / VGA / Ethernet
User Manual
Benutzerhandbuch
Manuel Utilisateur
Manuale
LINDY No. 43181
www.lindy.com
Tested to Comply with FCC Standards
For Home and Office Use!
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - Third Edition (JUNE 2015)
Overview
This LINDY USB 3.0 Notebook Docking Station allows you to connect
external peripherals to your notebook via a single USB 3.0 cable. It
features an HDMI and VGA video output for connecting either an HDMI
or a VGA monitor. Through the RJ45 port you can access a Gigabit
Ethernet Network. A USB 3.0 port allows connection of USB devices.
Features
•
USB 3.0 upstream port with USB 3.0 A plug
•
HDMI output port supports Full HD 1080p and 1920 x 1080
•
VGA output port supports up to 2048 x 1152
•
USB 3.0 downstream port
•
10/100/1000Mbps RJ-45 Gigabit Ethernet port
•
USB bus powered
•
Supported OS: Windows 7 / 8 / 8.1, MAC OS 10.9 and above
Package Contents
•
Notebook Docking Station
•
Driver CD
•
LINDY Manual
Installation and Use
Windows 8 / 8.1:
Connect the Notebook Docking Station to your computer. The required
drivers will be automatically downloaded from the internet.
Up to Windows 7:
Connect the Notebook Docking Station to your computer. Then download
the required drivers from http://www.displaylink.com
English
Deutsch
Français
Italiano
English
If your computer has no internet access, please install the drivers from
the enclosed CD. Then connect the Notebook Docking Station to your
computer.
Mac OS 10.9:
Please download and install the Mac drivers from the DisplayLink
website: http://www.displaylink.com and follow the on screen prompts.
English
Note:
English
English
•
When connected to both the HDMI and VGA monitors, the
docking station will automatically switch to the HDMI monitor
and disable the VGA monitor
•
When connected to a USB 2.0 port, the adapter may not
function properly due the limited power (USB 3.0 provides
900mA, USB 2.0 provides only 500mA)
