English
Front Panel Layout
Interfaces
2
1
General Information
The 4 in 1 Cable Tester works by pressing one single button on the
panel. The user can get the test results from the 8 LEDs and knows
the cable is connected, has no connection, is short or non-parallel.
Note: only one cable can be tested at a time.
S C/1 2
3
RJ-45/RJ-11/USB
SHORT
CONNECTED
NON-PARALLEL
NO CONNECTION
BATTERY GOOD
6
4
5
6
7
SHORT
25 OHM
50 OHM
NO TERMINATOR
BATTERY LOW
1 Test Button
2 Main Display
3
3 RJ45 jack
4 RJ11 jack
4
5 USB jack
6 BNC jack
5
3
4
5
-
-
2
8
Pin / Wires
Condition
BNC
