DESCRIPTION OF THE DEVICE

(1) Lens
(2) Housing
(3) Mounting bracket
(4) Fixation screw
(5) Microphone
(6) MODE button
(7) Power input

Remote control

Note: The remote control is supplied with a battery inserted. An insulating foil between the battery and the
battery contacts prevents the battery from being discharged during storage. Prior to the first operation
remove the foil from the battery support on the rear side of the remote control. Otherwise operation of the
remote control is not possible. To replace the battery press the small bar with the groove to the right and at
the same time remove the battery support. Pay attention that the positive pole of the button cell shows
upwards in the support.
Button Function
OFF Off
ON On
Auto 1 Color change: R-G-B
Auto 2 Color change: R-RG-G-GB-B-RB
Auto 3 Color change + strobe: R-RG-G-GB-B-RB
Sound 1 Sound-controlled color change: R-G-B
Sound 2 Sound-controlled color change: R-RG-G-GB-B-RB
Sound 3 Sound-controlled color change + strobe: R-RG-G-GB-B-RB
Motor Rotation motor on/off
Speed-/Speed+ Rotation speed down/up
Strobe Strobe effects: auto mode/sound-controlled mode/off
/ Flash rate down/up
Blue Blue
Green Green
Red Red
Green Blue Green + blue
Red Green Red + green
Red Blue Red+ blue
