Device functions
Video Connect the device to an external power supply, put the microSD card in and it will start recording auto
matically (indicated by the flashing blue light). Press the OK button to stop recording (the blue light will
become steady). Press OK again to record another video. Each video will be saved automatically.
Photo In Video Record mode, press the Power button to enter Capture mode, press the OK button to take a
photo (it will be saved automatically).
Playback Press Power button to enter Playback mode (in Video Record mode press the Mode button twice); press
the Up and Down buttons to select a file; press the OK button to play a file. During playback, press OK to
pause/unpause; press the Up and Down keys to fast forward/rewind.
In Video Record mode, press Down to protect the current recording. A key symbol will appear at the
Lock file
bottom of the screen. In Playback mode, select a file, press Menu and select Protect, then Lock Current
or Lock All. Protected files cannot be deleted or overwritten. Select Unlock Current/Unlock All to remove
protection.
Sound Record Choose this option to record video with or without sound.
Loop recording This setting allows saving the recording in separate files every few minutes. For example, if set to 60
seconds, 10 minutes of footage will be saved as 10 one minute fragments. If the memory card is full, all
unprotected files will be overwritten in the order they were created.
G-sensor If the vehicle is hit by something, the DVR will automatically lock the current video.
Stamp This function adds date stamp or device logo to the record. Press OK to select type of stamp or to
switch the function off. You can also choose GPS stamp to mark your location.
