ChaRgiNg
1. Connect one end of USB cable with the microUSB
port of the speaker.
2. Connect the other end with the AC charger or
compatible PC USB port.
3. When the speaker is charging, red LED is on.
4. When the device is fully charged, blue LED is on.
Note: Make sure the device is fully charged before first
use.

SPECiFiCatiONS

• Output power: 2x 5 W
• Frequency response: 100 Hz – 20 kHz
• Speaker: 2x 2,75"
• Impedance: 4 Ω
• Distortion: ≤ 1%
• S/N ratio: ≥ 85 dB
• Bluetooth 4.2
• Bluetooth range: up to 10 m
• FM radio (60 preset station memory)
• Inputs:
• Line input (jack 3,5 mm)
• USB port
• microUSB port (charging)
• microSD card slot (up to 32 GB)
• Working time: up to 2 h (full volume)
• Battery capacity: 1800 mAh
• Charging voltage: 5 V; 500 mA
• Set includes: USB charing cable, belt
