Schego prima Gebrauchsanleitung Seite 3

only for use in rooms
(to DIN 30600, Reg No. 02808)
max. approved delivery head: H max. 3m
Important: Choose location of the membrane pump
!
above the water surface height of the basin or use suita- .
ble non-return valves to prevent liquid flowing back into
the pump.
Observe without fail: Install or fasten the membrane
pump when starting up so that the unit cannot fall into
the water.
Attach hose connection, plug in mains plug.
Maintenance
Change the prefilter in the base plate regularly if contaminated.
In the case of loss of Performance and with strong contamination
also Change the white pump head:
bottom part and lift off housing cover. .4 Unscrew membrane
nut. 4 Loosen retaining screws on the metal rocker. *-:a Lift off
the metal rocker. --\ Pull off the membrane or replace the com-
plete pump head.
Assembly in the reverse Order.
Distance between magnet and coil approx. 1 mm.
If the connection cable of the unit is damaged, it must be repla-
ced by the manufacturer or its customer Service.
Spare Parts
Art No. membranes
100 I/h
prima
150 I/h
ideal
250 I/h
optimal
350 I/h
. .
A r t N o . coil
prima
ideal 150 I/h
optimal 250 I/h
350 I/h
Warranty
Material and processing defects which become apparent within
2 years of the date of sale will be rectified free of Charge with
free sending in. Membrane darnage and failures due to contam-
ination, water return or incorrect use are excluded from the war-
ranty Obligation.
pump head
pc.
732
772
filter felt
. , , " .,
733
773
853
741
