ASSEMBLY INSTRUCTION
1. Remove all parts from box.
2. Lay top of stand with the bottom side up on a soft surface to avoid scratching top.
3. Screw 4 upper legs into place.
4. Position base on top of the 4 upper legs with the bottom side up.
5. Screw 4 lower legs into place.
6. Place the metal dividers through the holes in the base with the angles side of the dividers towards the front of the stand.
7. Tighten all screws to secure unit.
8. Turn the stand upright.
STAND ASSEMBLY DIAGRAM
PARTS
QTY.
A. Top
1
B. Base
1
C. Upper Legs
4
D. Lower Legs
4
E. Plastic Foot 15 x 5 mm
4
F. Metal Dividers
2
G. Rubber Bushing
4
FINISHED STAND
ASSEMBLY
C
C
C
F
F
G
G
B
D
D
E
D
E
E
1
ESPAÑOL
ATENCIÓN AL CLIENTE
En caso de dudas o problemas con su producto Ricatech, contacte con el servicio de atención al cliente
de Ricatech. Para más información sobre el procedimiento completo, visite el sitio web de Ricatech en:
www.ricatech.com
A
C
D
E
10
