Quick installation guide IB-HUB1701-U3
Overview
1.
2.

Connection diagram

3. 4.
1. USB 3.0 host interface (Type-B)
2. DC power port
3. 7x USB 3.0 Type-A interface
4. 7x power LED
5. On/Off switch for each USB port
IB-HUB1701
5.
