Installation.
Application is simple: a submersible pump is connected directly to the staggered hose tail of the CompactSieve (1" / 1¼"
/ 1½"). Keep in mind to put the black elbow angled downwards. When you use hose size 1¼" or 1½" you can cut off the
other hose connections for a better flow. Mount the supplied piece of "U-profile" rubber on the upper edge of the sieve
(D) for easy maintenance without touching the sharp edge. Now install the return and overflow push fittings (figure C).
The water flows through the sieve and removes all particle matter down to a size of 0,
outlet C can be returned either to the pond or to the next biological filter. The CompactSieve must be installed above
pond water height.
Maintenance.
To clean sieve, lift handle (B) and pull sieve forward
then lift sieve gently out of chamber. Clean the sieve
from the backside with a hosepipe. To clean all brown
deposits you may require a stiff brush. Clean very
thoroughly to avoid clogging of the screen.
Specifications.
The stainless steel sieve is 24,5 cm wide and 40 cm
long and has slots of
up to a maximum of 15m³/hour. Output and overflow
are 75mm push fittings.
External dimensions:
(L) 50 x (W) 33 x (H) 56 cm.
C
o
m
p
C
o
m
p
User Manual
D
C
micron. Pumping speed is
a
c
t
S
i
a
c
t
S
i
A
B
C
®
®
e
v
e
e
v
e
A
mm. The clean water from
B
D
