1.4. Disposal Notes

Electrical equipment marked with the cancelled waste bin
symbol must not be discarded in the standard household was-
te; instead it should be taken to a suitable specialist disposal
system.
In the countries of the EU (European Union) electrical equip-
ment must not be discarded via the normal domestic refuse
system (WEEE - Waste of Electrical and Electronic Equipment,
Directive 2002/96/EG).

2. Connections, special features

Prepare the red positive and the black negative battery cables
for suitable plug/socket connectors. Isolate all solder con-
nections with heat shrink. Connect a suitable battery to the
Receiver (Rx) and take note of the Rx manufacturers recom-
mendations! Receiver, Receiver battery, Motor connection,
Programmer cable Speed controller, Power battery.
1 Receiver
Receiver battery
2
3 Motor connection
Programmercable
4
5 Motor controller
6 Drive battery

3. Specifi cation

Function (Choice)
Load current
Peak load
Dimensions (mm)
Weight (g)
Cell number
SPS
Rx-Filter
PCO
POR
hec
TP
Cool Power FET
Cooling fan
You can take unwanted equipment to your nearest local au-
thority waste collection point or recycling centre. There the
equipment will be disposed of correctly and at no cost to you.
By returning your unwanted equipment you can make an im-
portant contribution to the protection of the environment!
1
BL 975-12 Opto BL 9100-12 Opto
No. 31 8639
Forward - Stop - Brake - Reverse
75 A
85 A
78 x 29 x 14
79 g
14 – 36 NC / NiMH 14 – 36 NC / NiMH
4 – 12 LiPo
32 kHz
2
4
5
BL 9120-12 Opto
No. 31 8640 No. 31 8641
100 A
120 A
73,4 x 56 x 31 73,4 x 56 x 31
162 g
14 – 36 NC / NiMH
4 – 12 LiPo
32 kHz
3
6
120 A
150 A
166 g
4 – 12 LiPo
32 kHz
11
