10

LED DISPLAY

Displays the current operating mode and other information, such as system settings.
11
CONTROL BUTTONS
MODE: Press the MODE button to move up one level in the menu structure.
ENTER: Confirm programme selection and value changes.
UP and DOWN: Selection of the main menu items, programme selection, change settings, such as programme speed and DMX address
12
STATUS LEDs
DMX LED: The LED lights up as soon as the DMX-control mode is enabled.
SOUND LED: As soon as the sound-control mode (Sound Mode) is enabled, the LED flashes in time with audio pulses.
AUTO LED: The LED lights up as soon as the automatic-control mode is enabled.
SLAVE LED: The LED lights up as soon as the Slave mode is enabled.
13
MIC
Microphone for music-control mode
14
MIC SENSITIVITY MIN / MAX
Control dial for setting the microphone sensitivity in Standalone sound-control model and in DMX sound-control mode. Rotating to the left
lowers the sensitivity (MIN), and rotating to the right increases sensitivity (MAX).
15

KEY SWITCH

Lock switch for switching the laser on and off. In the OFF position, the laser is deactivated and in the ON position, it is activated. Two keys
are included. To ensure that the laser is not operated by unauthorised persons, lock the switch and remove the associated keys.
16
REMOTE
Connection socket for optional wired emergency stop switch to deactivate the laser effect. Use the supplied short-circuit connector order to
activate the laser effect if no emergency cut-off switch is connected.
17
SAFETY EYE
Eyelet for safety rope. Overhead installation must only be carried out by qualified personnel. The spotlight must be fitted with a suitable
safety rope to ensure that it does not fall down.
PLEASE NOTE: Case fans are situated on two sides of the housing. In order to avoid overheating of the device, ensure that the fan is not
covered and that air can circulate freely.
