The electrical diagram must be adapted to the installation to be implemented. For more complex installations than those
presented below, please consult the diagrams book available as a pdf.
Note: The external module can control an electric lock or a motorised gate. To control both, a relay module is required, ref.
9020031.

7.1 Installation with an external "1-button" module and a monitor

1
See diagram at the end of the document.

7.2 Installation with an external "1-button" module and two monitors

Bus line between the two monitors
2
See diagram at the end of the document.
Bus line distributed via the electric panel
3
See diagram at the end of the document.

7.3 Installation with an external "2-button" module and two monitors

4
See diagram at the end of the document.

7.4 Push button for a remote buzzer

It is possible to connect an independent push button enabling the buzzer on the monitors to ring with a different tune
from that used for calls from an external module.
Copyright © 2016 Somfy SAS. All rights reserved.

7 ELECTRICAL DIAGRAMS

9020027 9020027
0 0 230V 230V +BUS- +BUS-
N L
230 VAC
50 Hz
