PREPARATION

Remove the plastic cover on the back side of the remote control and insert the battery

STARTUP

1 Insert the remote socket you want to connect with the remote control into a mains socket
2 10 second after insertion, press one of the ON buttons on the remote control to connect the
wireless socket with one of the 4 remote channels (A, B, C or D)
3 The remote socket is now connected to the remote control You can now insert the device
you wish to switch on and off into the connected remote socket

FUNCTION CHECK

4 Check the functionality by pressing the ON button for the selected letter (A, B, C or D) If
you hear a "click" sound, the remote socket is ready to use.
5 Press the OFF button for the same letter. When you hear another "click" sound, the remote
socket is switched off

REVERSING THE CONNECTION

6 Use the respective OFF button (A, B, C or D) on the remote control to turn off the remote
socket
7 Remove the remote socket from the mains socket and wait for about 5 seconds
8 Now reinsert the remote socket into the mains socket
9 Now press the OFF button for the same channel within 10 seconds
10 Remove the remote socket from the mains socket
The remote socket is now disconnected from the remote control and can be assigned to another
button (A, B, C or D). To do so, start again with the first step of the "Startup" process.
- 10 -
NOTES
• The remote sockets are switched on and off using the ON / OFF buttons on the remote
control
• The red LED on the remote control illuminates briefly when pressing a button The red LED
on the remote socket lights up for as long as it is switched on
• The wireless range declines, when the signal has to pass through obstacles The total
transmission distance is massively depending on the local conditions
• The ON/OFF button in the "ALL" section can be used to switch all remote sockets on /
off at the same time
TIPPS
If the remote control is not working, check the following:
1 Correct battery insertion – Watch the polarity!
2 Fill level of the battery; if the battery is empty, replace it with a similar one (AAA)
• Avoid liquids on the battery contacts
• Do not install the remote socket next to a transformer or other high frequency sources as
these can affect the wireless connection
• Do not exceed the maximum values, as specified in this manual
• Do not use the remote sockets for devices with a high switch-on voltage such as neon
lights, motors, etc
If the wireless unit does not work, check the following:
1 Proper function of the connected remote socket
2 Proper connection between remote control and remote socket
If you do not hear a clearly audible "click", the remote socket is not connected to the remote control.
Please repeat the "Startup" procedure.
3 Function of the connected device
4 Internal power supply of the inserted device (ON/OFF switch)
- 11 -
