Operating Instructions
CC1 - Smart WiFi Power Strip
Item No. 1557804
Intended use
The product is equipped with 6 receptacles and an overcurrent protection. The product can connect to your
WLAN and be controlled from an accompanying app and your Conrad Connect account via the Internet.
Via the app the user can for example set timer and schedule, view real-time power consumption and
the energy usage history. More functions are available, depending on the scope of functions your device
supports.
The product is intended only for the connection to a standard power socket with earth contact. Refer to the
technical data section to learn more about the maximum permissible loads.
The product is only designed for indoor use. Keep away from water and high-humidity sources and the areas
where these conditions occur (e.g. bathroom).
Please read the operating instructions carefully and do not discard them. If you pass the product on to a third
party, please hand over these operating instructions as well.
Any use other than that described above could lead to damage to this product and involves the risk of short
circuits, fire, electric shock, etc. No part of the product may be modified or reconfigured! Please observe the
safety instructions at all times!
This product complies with the legal national and European requirements. All names of companies and
products are the trademarks of the respective owners. All rights reserved.
Package Contents
• WiFi Power Strip
• Operating Instructions
Application
There are compatible Android and iOS apps
available from the respective app stores. Look
for the "Sygonix Home" app and download it onto
your smart device.
An app instruction manual is available from
the URL listed in chapter "Up-to-date operating
instructions".
Up-to-date operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or
scan the QR code. Follow the instructions on the website.
Explanation of symbols
The lightning symbol inside of a triangle is used when there is a potential risk
of personal injury, such as electric shock.
This symbol indicates specific risks associated with handling, operation or use.
The arrow symbol indicates special tips and operating instructions.
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe these safety
instructions! We do not assume any liability for any resulting damage! We shall not
accept liability for damage to property or personal injury caused by incorrect handling or
non-compliance with the safety instructions! The warranty/guarantee will be void in such
cases!
a) General
• The unauthorized conversion and/or modification of the product is not allowed for safety and
approval reasons. Do not open/disassemble!
• The product is designed in accordance with protection class I. Only a standard grounding
mains socket of the public supply grid (a wall socket, for example) may be used as a power
source.
• The mains socket into which the product is plugged must be easily accessible.
• The product is not a toy and should be kept out of the reach of children. Position the product
so it is out of the reach of children.
• The product is equipped with a child safety lock. An integrated mechanism will release the
holes of the receptacle only, if the two prongs of a power plug are inserted into the two holes
at once. Nevertheless, take special caution when children are around. Children cannot
recognize the danger arising from the incorrect use of electrical devices. There is a risk of a
life-threatening electric shock!
• Do not leave the packaging material lying around carelessly as it may be a danger to children.
• Handle the product with care; it can be damaged by impacts, blows or falls even from a low
height.
• If you have any questions that are not answered in this manual, please contact our technical
service or another specialist.
b) Mains cable
• Completely unwind the mains cable when using the power strip.
• Lay the cable such that nobody will trip over it.
• Make sure that the mains cable is not squeezed, bent, damaged by sharp edges or put under
mechanical stress.
• Avoid excessive thermal stress on the mains cable from extreme heat or cold.
The product is compatible with the Conrad
Connect IoT platform at
www.conradconnect.de
• Do not modify the mains cable. Otherwise the mains cable may be damaged. A damaged
mains cable can cause a deadly electric shock.
• Never use the product if the mains cable is damaged.
• Do not touch the mains cable if it is damaged. First, power down the respective mains socket
(e.g. via the respective circuit breaker) and then carefully pull the mains plug from the mains
socket.
• A damaged mains cable may only be replaced by the manufacturer, a workshop commissioned
by the manufacturer or a similarly qualified person, so as to prevent any danger.
c) Operating location
• The product may only be used in dry interiors; it must not get damp or wet! Never position
the product in direct vicinity of a bathtub, shower, bathroom, swimming pool, or similar. Lethal
hazard due to electric shock!
• The product must not be exposed to extremes of temperature, direct sunlight or strong
vibrations. Keep the product away from strong magnetic fields generated by machines,
electric motors or loudspeakers.
• Do not operate the device in environments where there are high levels of dust, flammable
gases, vapours or solvents. There is a danger of fire and explosion!
• The device can warm up during use. Make sure not to place it on sensitive surfaces.
• Do not use this product in hospitals or medical institutions. Radiowaves may interfere with
medical equipment. The same may also apply to other areas.
d) Handling and Use
• Never plug in, unplug or operate the product when your hands are damp or wet. There is a
risk of a life-threatening electric shock! The same applies for the load that is plugged into the
socket of the product.
• Never connect the product to the power supply immediately after it has been transferred
from a cold room into a warm one (e.g. during transport). The condensation that forms might
destroy the device. Moreover, there is danger of electric shock! Allow the product to reach
room temperature. Wait until the condensation has evaporated. This might take several hours.
Only then the product may be plugged into the mains socket and put into use.
• Always use the gripping surface to pull a mains plug out of the product. Never unplug a mains
plug from a mains socket by pulling the cable.
• Never overload the product. Note the maximum permissible connected load in the chapter
"Technical Data".
• Do not connect in series! This can lead to an overload of the product! There is a risk of fire!
• Do not operate while covered! At higher connected loads, the product becomes warm, which
can lead to overheating and potentially a fire if covered!
• Disconnect the product from the mains socket in thunderstorms for reasons of safety.
• Volt-free only, if unplugged!
• Do not use the product if it is damaged. There is a risk of a life-threatening electric shock! In
this case, dispose of the product in an environmentally correct manner. Safe operation can
no longer be assumed if:
- the product shows visible signs of damage
- the product does not work at all or works poorly (leaking smoke or a smell of burning,
audible cracking noises, discolouration to the product or the adjacent surfaces)
- the product was stored under unfavourable conditions
- it was exposed to heavy loads during transport
• Never pour any liquids above or next to the product. You run the risk of causing a fire or a
fatal electric shock. If any liquid has still managed to enter the device, immediately switch off
the power supply to the mains socket at which the product is connected (turn off the fuse /
circuit breaker / residual current operated circuit breaker of the associated circuit). Only then
can you unplug the product from the mains socket and contact a specialist. Do not use the
product any longer.
• Always pull the product out of the mains socket (e.g. wall socket) before cleaning it or when
the device will not be in use for a long time (e.g. for storage).
• Use the product only in a temperate climate, never in a tropical climate.
Control Elements
9
8
7
1
Mains cable
2
WLAN indicator light
3
On/Off indicator light
4
USB socket
5
Reset button
6
Receptacle
7
Openings for wall mounting
8
Reset switch RESET/OFF
9
Port indicator light
1
2
3
4
5
6
