Rockford Fosgate PUNCH P1650 Bedienungsanleitung
  1. Anleitungen
  2. Marken
  3. Rockford Fosgate Anleitungen
  4. Auto Lautsprecher
  5. PUNCH P1650
  6. Bedienungsanleitung
Rockford Fosgate PUNCH P1650 Bedienungsanleitung

Rockford Fosgate PUNCH P1650 Bedienungsanleitung

Vorschau anzeigen
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Verfügbare Sprachen

Verfügbare Sprachen

  • DEUTSCH, seite 14

Quicklinks

Diese Anleitung herunterladen
121914
1230-57046-02
Printed in China
loading

Verwandte Anleitungen für Rockford Fosgate PUNCH P1650

Inhaltszusammenfassung für Rockford Fosgate PUNCH P1650

  • Seite 1 121914 1230-57046-02 Printed in China...
  • Seite 2 fire and/or possible injury. ©2011 Rockford Corporation. All Rights Reversed. ROCKFORD FOSGATE, PUNCH, and associated logos where applicable are registered trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
  • Seite 3 Specifications...
  • Seite 4 Specifications P132 4.50" (114.07mm) 2.11" (53.4mm) 1.46" (37.0mm) 0.26" 3.21" (6.70mm) (81.59mm) 4.31" (109.40mm) P142 5.08" (129.0mm) 3.20" (81.3mm) 4.53" (115.0mm) Diameter 2.46" (62.4mm) 1.75" (44.5mm) 4.04" (102.5mm) P152 6.02" (153.0mm) 3.84" (97.6mm) 5.43" (138.0mm) 6.22" Diameter 0.88" (158.0mm) (22.3mm) 2.59"...
  • Seite 5 Specifications 6.14" (156.0mm) 4.31" (109.6mm) 6.69" 6.10" (170.0mm) 6.89" (155.0mm) 0.94" Diameter (175.0mm) Diameter (23.8mm) 5.59" (142.0mm) Diameter 2.89" (73.4mm) 1.93" (49.0mm) 5.05" (128.2mm) P1650 6.5” (165mm) 4.3” (110mm) 6.1” (156mm) 2.9” (75mm) 2.2” (57mm) 5.5” (140mm) P1675 6.77" (172.0mm) 4.37"...
  • Seite 6 Specifications P1462 6.48" (164.6mm) 4.84" (123.0mm) 4.37" (111.0mm) 3.76" (95.6mm) 4.23" (107.4mm) 2.38" 3.15" (60.4mm) (80.0mm) 1.85" 2.91" (47.0mm) (70.5mm) 6.01" (152.6mm) P1572 8.72" (221.6mm) 8.27" (210.0mm) 7.88" (200.1mm) 4.31" (109.4mm) 4.76" (120.9mm) 5.68" (144.2mm) 2.72" 5.02" (69.2mm) (127.6mm) 2.3" (58.5mm) 3.54"...
  • Seite 7 Specifications P1692 9.37" 7.56" (238.0mm) (192.0mm) 6.60 " (167.7mm) 6.61" (168.0mm) 4.78" (121.5mm) 5.77" (146.5mm) 10.24" (260.0mm) 0.80" (20.4mm) 3.53" (89.6mm) 3.07" (78.0mm) 8.51" (216.2mm) P1694 9.37" 7.56" (238.0mm) (192.0mm) 6.60 " (167.7mm) 6.61" (168.0mm) 4.78" (121.5mm) 5.77" (146.5mm) 10.24" (260.0mm) 0.80"...

  • Seite 8: Installation Considerations

    Installation 5. On models with slotted holes, fit the speaker into the cutout and Contents install the screws in the slots at the top and bottom.This will allow • (1) Pair Punch Series Full Range Speakers you to rotate the speaker to match the remaining mounting holes. When aligned, tighten the screws.
  • Seite 9 Installation Adapter Plate Template - 6.75” Hole Mounting Remove Shaded Areas to Mount 5.25" (P152) Remove Shaded Areas to Mount 6" (P16) illus.-3.1...
  • Seite 10 Installation Adapter Plate Template - 5”x7” Hole Mounting Remove Shaded Areas to Mount 4" (P142) Remove Shaded Areas to Mount 4"x6” (P1462) illus.-3.2...
  • Seite 11 Installation Adapter Plate Template - 6”x9” Hole Mounting Mounting for 5.25” (P152) *Remove Light Shaded Areas *Remove for Optional Tweeter for 5”x7” Hole Mounting Remove Dark Shaded Areas to Mount 6" (P16) *Remove Light Shaded Areas *Remove for Optional Tweeter for 5”x7”...

  • Seite 12: Considérations Concernant L'installation

    Français 7. Serrez les vis jusqu’à ce que le haut-parleur soit bien ajusté, de façon à Considérations Concernant L’installation prévenir tout cliquetis, mais évitez tout serrage excessif.REMARQUE: Avant de commencer l’installation, suivez les règles ci-dessous: Nous recommandons l’utilisation d’un fil de 4AWG pour les prises d’alimentation (B+) et de masse (GND).

  • Seite 13: Consideraciones Para La Instalación

    Español acabado arriba del altavoz y móntelo en su sitio usando cuatro (4) Consideraciones para la instalación tornillos. Antes de comenzar cualquier instalación, siga estas simples normas: 7. Apriete los tornillos hasta que el altavoz esté ajustado en su sitio para 1.

  • Seite 14: Einbauüberlegungen

    Deutsch 6. An Modellen mit einem Zierring den Zierring über den Lautsprecher Einbauüberlegungen legen und mit 4 (vier) Schrauben an seinem Platz befestigen. Befolgen Sie vor dem Einbau diese einfachen Regeln: 7. Die Schrauben anziehen, bis der Lautsprecher eng an seinem Platz 1.

  • Seite 15: Considerazioni Sull'installazione

    Italiano 7. Per evitare rumore dovuto a vibrazioni serrare le viti finché il diffusore Considerazioni sull’installazione non sia saldamente in posizione. Non serrare le viti in modo eccessivo. Prima di iniziare qualsiasi operazione d’installazione, vi consigliamo di NOTA: Nel caso dei P142, P1462, P152, P16 e P1675 solamente, montare seguire queste semplici regole: il diffusore servendosi, se necessario, della piastra di adattamento in dot- azione.
  • Seite 16 What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country’ s Distribu- tor and not by Rockford Corporation.
