D-Link DIR-518L Schnellinstallationsanleitung Seite 4

PrODUCT SETUP
ConneCTinG To THe dir-518l
Step 1
Turn on the DIR-518L by sliding the Router/Charger switch to Router.
Step 2
On your PC or mobile device, connect to the DIR-518L's wireless network. Locate the Wi-Fi name
(SSID) and password for your device as printed on the included Wi-Fi Configuration Card.
Step 3
Once connected, open a web browser on your mobile device or computer and type
http://dlinkrouter.local. or http://dlinkrouter. in the address bar.
Step 4
At the login page, enter the Admin Password. By default, it should be left blank. Click Log In.
ConFiGurATion
After logging in, you will see a status page. If the Internet icon
If the Internet icon
Using a Wired Ethernet Connection:
Enter the Username and Password given to you by your Internet Service Provider.
Using a 3G USB Adapter:
If your SIM requires a PIN, enter it and click Save. If necessary, the wizard may ask you to
enter the APN, Dial-Up Number, Username, and Password details given to you by your service
provider.
Connecting to a Wi-Fi Hotspot:
Select an available hotspot and enter its password to connect.
MAnAGinG Your ConneCTions
Connection configurations will be automatically saved as Internet Profiles for future use. The
DIR-518L will connect to them automatically when they are available. If you have more than one
connection available, you can manually select the connection you wish to use.
To select a connection:
- Go to Settings>Internet
- From the Profile List, you can select the radio button next to your Profile Name to use this
connection.
For more details on how to add, delete, or edit profiles, please refer to Internet Profiles in the User
Manual.
4
If the password is not blank or you have forgotten the password, reset the router
by pressing the RESET button with a pin for 5 seconds or more, then release.
is grey and there is a
is blue, the device is ready for use!
icon, click on the icon and follow the steps below:
dir-518l
