Epomaker SPLIT70 Schnellstartanleitung Seite 4

BATTERY CHECK
1. Hold FN+B, backlight will be off, keys from 1! to 0) will lights up indicating
current battery percentage. For example, if 1! to 6^ lights up, then the
keyboard battery percentage is 60% ; if 1! to 0) lights up, then the
keyboard battery percentage is 100%.
2. Press and hold FN+Space to check Charging Status: When the FN key
indicator is solid red, it means the device is currently charging. If the FN
key indicator turns green, the device is fully charged.
*Note:
1. The keyboard charges under either Wired or Wireless connectivity with
the device as long as the keyboard in plugged in.
2. Don't use Charger to charge the keyboard.
LIGHT INDICATOR
1. Caps Key: The indicator lights up when enabled.
2. Win Key: The indicator lights up when disabled.
3. Hold FN key: Q/W/E/R/T lights up indicate the current connectivity，
A/S lights up indicate the current OS.
4. Low Battery: FN key flashes
WIRELESS SLEEP MODE
1. The backlight will turn off after 5 minutes of inactivity. Simply press
any key to reactivate the lighting
2. The keyboard enters sleep mode after 30 minutes of inactivity,
turning off the backlight and disconnecting from the device. Press any
key to wake it up and reconnect.
HOW TO ENTER DFU (FIRMWARE UPDATE) MODE
● Left Half (with knob):
1. Disconnect all cables from the keyboard.
2. Hold ESC and plug in USB-C.
3. "Device Connected" shows on the QMK Toolbox
● Right Half (with arrow keys):
1. Disconnect all cables from the keyboard.
2. Remove ALT and FN Keycaps and Flip the toggle switch between them
down.
3. Remove Right Spacebar keycap and switch, short-circuit PCB holes with
tweezers, then plug in USB-C.
4. "Device Connected" shows on the QMK Toolbox
5. After flashing, flip ALT/FN toggle back up.
● Please reset the keyboard after flashing is completed.
*Notes:
1. When updating or flashing the keyboard, MAKE SURE ONLY ONE
KEYBOARD IS CONNECTED TO THE DEVICE!
2. When updating or flashing the keyboard, DON'T MOVE THE KEYBOARD
or PRESS ANY KEYS!
HOW TO CONNECT TO VIA
1. Please visit "https://www.usevia.app/" and connect the keyboard to
your device using a wired connection. Turn Off the button of "Use V2
Definition(Deprecated)".
↓
