INSTALLATION

Please consider the
installation! The installation must only be carried out by an authorized dealer!
When rigging, derigging or servicing the fixture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert before taking into operation for the first time and after changes before taking into operation another
time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a
skilled person once a year.
Procedure:
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all
installation material and the loads. If you lack these qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper installation can result in bodily injury and.or damage to
property.
The stand has to be installed out of the reach of people.
Installation
Loosen the fixation screw of the legs. Pull the legs out until they stand at a 45° angle to the tube stand.
Tighten the fixation screw of the legs.
Caution: The loads have to be installed in a balanced way.
Caution: The carrying capacity of the stand must never exceed 15 kg!
Loosen the fixation screw of the telescopic tube. Carefully pull out the telescopic tube to the desired height.
Please ensure, that the bore-hole for the safety bolt is always located directly above the stand tube stop.
Important!! The maximum extension height should never be exceeded.
Tighten the fixation screw. Insert the safety bolt as a secondary securing into the bore-hole of the telescopic
tube.
Before taking into operation for the first time, the installation has to be approved by an expert!
DANGER TO LIFE!
DIN 15560-27 and the respective national norms during the
DANGER TO LIFE!
11/12 60004020_V_1_0.DOC
