Tank Emptying - Ecoflex Sc500 Gebrauchsanweisung

ENGLISH
Working with brush extra pressure function turned on
If the floor proves to be particularly difficult to clean, it is possible to turn on the brush extra pressure function, according to the
following procedure:
1. Press the push-button (43) to lower the brush deck as shown in "Starting The Machine" paragraph.
2. Press and hold the push-button (43) for more than 1 second.
The extra pressure function activation is shown by LED which turns from green to red, and by the icon
(50).
3. To return to normal pressure, press and hold the push-button (43) for more than 1 second.
4. To lift the brush deck without returning to the normal pressure, press the push-button (43) and release it immediately.
CAUTION!
In case of brush motor overload, due to foreign bodies which prevent them from turning, or to excessively
aggressive floors/brushes, the safety system stops the brush after about one minute of continuous overload.
If the overload takes place when the extra pressure function is on, the system automatically turns the extra
pressure function off.
If the overload persists, the brush stops.
To start scrubbing again after a brush stop due to overload, turn off and then on the machine with the push-
button (42).
Battery discharge during operation
When there is only one segment turned on and flashing on the battery symbol (50-C), it is advisable to charge the batteries,
because the residual autonomy will last for a few minutes (depending on battery characteristics and work to be performed).
When the battery symbol (50-C) is flashing and no segment is turned on, the battery autonomy is over. After a few seconds, the
brush is automatically tuned off, while the vacuum system and the drive system stay on, to finish drying the floor and drive the
machine to the appointed recharging area.
CAUTION!
Do not use the machine with discharged batteries, to avoid damaging the batteries and reducing the battery life.

TANK EMPTYING

An automatic float shut-off system (31) turns off the vacuum system when the recovery tank (33) is full.
The vacuum system deactivation is signalled by a sudden increase in the vacuum system motor noise, and the floor is not dried.
CAUTION!
If the vacuum system turns off accidentally (for example, when the float is activated because of a sudden
machine movement), to resume the operation: turn off the vacuum system by pressing the push-button (47),
then open the cover (19) and check that the float inside the grid (31) has gone down. Then close the cover (19)
and turn on the vacuum system by pressing the push-button (47).
When the recovery tank (33) is full, empty it according to the following procedure.
Recovery tank emptying
1. Raise the brush deck by pressing the push-button (43).
2. Lift the squeegee (29) with the pedal (8).
3. Drive the machine to the appointed disposal area.
4. Turn off the machine with the push-button (42) and remove the operator key (41).
5. Empty the recovery tank (33) with the drain hose (12). Then, rinse the tank with clean water.
Solution tank emptying
6. Perform steps 1 to 4.
7. Empty the detergent solution tank (21) using the level hose (13). Then, rinse the tank with clean water.
16
INSTRUCTIONS FOR USE
SC500 - 9099974000
on the display
11/14
