Connections and controls

CH 1 CH 2 CH 3 CH 4
DMX OUT
4
1
POWER
CH 5 CH 6 CH 7 CH 8 CH 9
2 3
CH 10 CH 11 CH 12 MASTER
DC INPUT
POWER
9V DC
OFF ON
5 6
1 Power indicator
2 Channel fader 1-12
The channel faders allow
up to 12 DMX channels to
be controlled individually
3 Master fader
The master fader controls
all channels simultaneously
4 DMX512 output
Connects the DMX input of
the first fixure in the DMX
chain
5 Power on/off
Switches the controller on
and off
6 Power input
Plug in the mains cable
of the power adapter here
English 9
