Bedienungsanleitung EK18plus
___________________________________________________________________________________________________________________

8. Technische Daten

Gewicht des kompl. Gerätes:
Preßkraft:
Hub:
Antriebsmotor:
Akkuspannung:
Akkukapazität:
Akku-Ladezeit:
Preßzeit:
Pressungen pro Akku:
Hydrauliköl:
Umgebungstemperatur:
Schalldruckpegel:
Vibrationen:
Maße:
Anmerkung
Diese Bedienungsanleitung kann jederzeit kostenlos unter der
Bestell-Nr. HE.4876_G nachbestellt werden.
ca. 3,7 kg (inklusive Akku)
ca. 60 kN
17 mm
Gleichstrom-Permanentfeldmotor
12 V
2,6 Ah
ca. 1 h [LG 4], bzw. ¼ h [LG5]
3 s bis 6 s (abhängig vom
Verbinderquerschnitt)
ca. 160 Pressungen
(Cu 150 mm² DIN 46235)
ca. 65 ml "Shell Tellus T 15"
-20°C bis +40°C
70 dB (A) in 1m Abstand
< 2,5 m/s²
(gewichteter Effektivwert der
Beschleunigung)
Siehe Bild 2
Instruction Manual
for the electric-hydraulic crimping unit Type EK 18 Plus,
Serial-No. ............................
Index
1 Introduction
2 Labels
3 Warranty
4 Description of the electric-hydraulic crimping unit
4.1 Description of the components
4.2 Brief description of the important features of the unit
4.3 Description of the light diode display
5 Remarks in respect of the determined use
5.1 Operation of the units
5.2 Explanation of the application range
5.3 Mounting instructions
5.4 Service and Maintenance instructions
5.5 Remarks on the use of the Battery Cartridge and Charger
5.6 Storage and transport of the crimping unit.
6 Troubleshooting
7 Putting out of operation/waste disposal
8 Technical data
Symbols
Safety warnings
Please do not disregard these instructions in order to
avoid human injuries and environmental damages.
Operational warnings
Please do not disregard them to avoid damaging the pump
unit.
1. Introduction
Before starting to use the tool please read the
instruction manual carefully.
Use this tool exclusively for its determined use.
Mounting and assembly of connecting material with the help of this tool
must only be performed by specially trained personnel. The minimum
age is 16 years.
This instruction manual has to be carried along during the entire life
span of that tool.
The operator has
- to guaranty the availability of the instruction manual for the user and
- to make sure, that the user has read and understood the instruction
manual.
2. Labels
On the labels fixed on the housing of the tool you'll find the type
specification name of the manufacturer and the company logo. On the
opposite side of the housing you'll find a label with a brief presentation
of the scope of manageable cross-sections for copper and aluminium and
the pressing force. The serial number is on the hydraulic cylinder
between the housing and the crimping head. On the crimping head you'll
find a warning against possible injuries during the crimping process.
3. Warranty
If correct operation is guaranteed our warranty is 6 months from the time
of delivery unless otherwise specified by local guidelines and law.
4. Description of the electric-hydraulic crimping unit
4.1. Description of the components
The electric-hydraulic crimping unit type EK 18 Plus is a hand held tool
and consists of the following components:
