03. NOTES
1. Damage caused by failure to follow these instructions will void the warranty.
2. The manufacturer is not liable for damage caused by improper use and
failure to follow safety rules.
3. For safety reasons, it is prohibited to make any changes or modifications
to the product.
4. Check the device regularly for damage. If the product is damaged, contact an
authorised service centre.
5. Do not pour liquids onto the product, as this may cause permanent damage
to the equipment and there is a high risk of fire.
6. The device should be kept out of the reach of children.
7. Use the product with care. Shock, impact or falling, even from a low height,
8. Do not use the device in environment exceeding 60℃, and do not store it in
may damage the product.
places exposed to high temperatures or humidity.
04. INSTALLATION
It is recommended to place the device on the passenger side and secure it with the
straps included in the set so that it does not interfere with driving and allows the
driver to operate the device freely.
05. START-UP
1. Connect the splitter plug to the 12/24V cigarette lighter socket in the car.
2. Start the vehicle.
3. If the device is correctly connected to the power supply, the voltage and
current to which the device is connected will appear on the display.
4. To power a device via the cigarette lighter socket, plug it into one of the
sockets in the splitter and press the button next to the socket to turn it on.
The socket is on when its power button is surrounded by a ring of light.
5. If you want to connect the device to the power supply via the USB port,
simply connect it using the appropriate USB cable.
6. If you are not using the splitter or have switch off the vehicle's engine, turn
off the main power button to save energy.
06. TECHNICAL SPECIFICATIONS
￭ Input: DC 12-24V ￭ Total power: 120W (Max) ￭ USB Type-C output (PD35W):
5V⎓3A; 9V⎓3A; 12V⎓2.92A; 15V⎓2.33A; 20V⎓1.75A ￭ USB-A output (QC3.0):
5V⎓3A; 9V⎓2A; 12V⎓1.5A (18W Max) ￭ USB Type-C (2)/USB-A (2)/USB-A (3)
output: 5V⎓3.1A ￭ Built-in 10A fuse ￭ Overheating/overcharging/overvoltage
protection ￭ Cable length: 100cm ￭ Dimensions: 122x38x74mm ￭ Weight: 190g
