Installation diagram (guideline)

The following is a simplified illustration of the typical installation layout and is purely guideline.
Distributor
by-pass
UN003414-EW
English language
INSTALLATION INSTRUCTIONS
Distributor
Pump
Delivery line
lter
Bar
Tank
Agitation
Relief valve
by-pass
Intake
