HOMCOM 842-289V90 Bedienungsanleitung Seite 9

Lighting
WARNING:
NEVER light the burner with a cover on the outdoor firepit.
CAUTION:
Keep outdoor gas appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
CAUTION:
Do NOT obstruct the flow of combustion and ventilation air.
CAUTION:
Check and clean burner/venturi tubes for insects and insect nests. A
clogged tube can lead to a fire.
1. Make sure all packagings have been removed from the outdoor firepit.
2. Check for obstructions of airflow to the burner Spiders, insects and webs can
clog the burner/venturi tube. A clogged burner tube can lead to a fire.
3. Control knob must be in the "OFF" position.
4. Clear small area of lava rocks away from the igniter cover.
5. Connect cylinder per "Connecting Cylinder" section.
6. Push and turn control panel counterclockwise to "High" position.
7. Use a match or a lighter to light the fire bowl (see Figure 8). Continue to press the
control knob for 15 seconds before it is released.
8. Adjust flame to desired height with the control knob.
9. After lighting, observe the burner flame Make sure all burner ports are lit and
flame height matches illustration (see Figure 9-11)
control knob
Figure 8
Needs Cleaning
Figure 10
Yellow
Light Blue
Blue
Figure 9
Best Flame
Figure 11
8
Yellow
Light Blue
Blue
