Absima Thrust ECOV2-PRO Bedienungsanleitung

Absima Thrust ECOV2-PRO waterproof brushed speed controller (ESC)
Dearuser,thank you for purchasing this product! Dueto the power by this product increasingwhen it is started to
use, incorrect use and operation may cause personal injury and equipment damage.
Therefore,we recommend that you read this manual careful y before using the equipment, and strictly abide by the
prescribed operating procedures. We do not assume any liability for random disassembly, modification or third-party
products, including but not limited to compensation for incidental or indirect losses.
FEATURES:
• Real car mode: Use the idle channel of the remote control to switch the vehicle direction in real time. Provides switching
between D and Rgears similar to real cars. The throttle back function is similar to the brake pedal function of a real car.
Providesa new control experience (real car mode can be setthrough convenient jumpers)
• Convenient jumpers enable 6.0V/7.4V/8.4V 5A three-speed BECoutput switching to meet different steering gear needs &
provide powerful power supply capabilities for climbing vehicles such as light sets and winches.
• The drag-and-kill intensity can be adjusted through the idle channel of the
ly adjust the drag-and-kill intensity in real time through the remote control.
• Provides forward rotation with brakes, forward
multiple modes for real cars to suit various control needs.
• Aluminum alloy shel provides excellent heat dissipation.
• Provide up to 13 programming settings. (Optional available—Art. 2110063).
Specification:
1. Cont./Burst Current: 80A/320A
2. Resistance: 0.00140hm
3. Motor Type: 540/550 size brushed motor only BROWN S IGNA
4. Battery: 2 3S LiPo, 4-9 Cells NiMH
5. Suitable Cars: 1/10 Brushed Crawler or car
6. BEC: 6.0V/7.4V/8.4V switchable and 5A (switch mode)
7. Dimension: 26.6mm
8. Weight: 66g (including wires)
Installation & connectors
• JUMPER set the Esc
ES C uses the jumper cap to set BECvoltage 6.0V or 7.4V or 8.4V and "REAL CARMODE" ON or OFF.
Wire connection
Single yellow cable: This cable is used to connect the receiver AUX channel and cooperate with the "real car mode" in the
running mode of esc to realize the function of real-time switching of motor rotation direction through the transmitter. For
details, please refer to the introduction of "real car mode" below the parameter items.
Single brown cable: This cable is used to connect the receiver AUX channel, which can realize the function of real-time
adjustment of drag brake force through the transmitter.
INSTRUCTIONS:
1. Connect the BEC wire with the receiver.
2. Connect the motor wires with ESC.
3. Always turn on the transmitter first
4. Connect battery pack with ESCand switch on the ESC.
5. When the connection of motor and battery is finished, the motor emits a "Beep-Beep" tone.
6. When the throttle stick is in the neutral position, the motor re-emits "Beep" tone.
7. The ESC is now workable.
TROUBLESHOOTING:
1. If after power on, motor can't work, no sound is emitted, please check the connections between battery pack and motor.
2. If the motor emits a "Beep Beep"tone Only, please check all the connections: BECwires, transmitter and receiver, throttle
signal wires, etc. please check the transmitter TH.TRIM and adjust it to the motor re-emits "Beep-Beep"tone
3. If the car can't be speed up, please check either voltage of the battery pack is too low or the temperature of ESCis too
high. If the voltage of the battery pack is too low, please replace the battery pack. If the temperature of ESCis too high,
please check all connections. If not, please push the button EPAon your remote control.
4. If the car stops suddenly while in working state, please check the motor's connections, and the roadblock.
MANUAL
Crawler Version
remote control, making it easy to dynamical
and reverse rotations with brakes, direct forward
FANSIGNAL SWITCH
CABLE
CAB E
YELLOW SIGNA ESC
CABLE
RECEIVER
IGNAL CABLE
CUSTOMIZING THE ESC
To begin, connect the ESCbattery wires to a charged battery, then connect the BECwire 3Pin wire to
the program card"S+-"port ( 3Pin port). Turned on the ESC , the programming cardwill automatica
ly read the ESCsettings, and the setting items of the programming card will display 1 to 15
successively,indicating that the connection is successful.You can start programming ESC. ( if it is not
displayed, it means that the connection is unsuccessful, please try to turn off ESCrepeatedly,
reconnectthe programming cardand turn on ESC again until it is successful)
TIPS! Program box is done using the 4 buttons below on the led, The function of each button start
from right hand side are ITEM, VALUE, 0K and RESET.
Please refer to the menu below to program the function settings you need.
"ITEM" button-----------------go
"VALUE" button
"0K" button-
"RESET" button-
Low Voltage Cut-Off: The function is mainly to prevent the lithium battery pack from over discharging.When using
lithium battery pack, pleaseset the suitable value for low-voltage protection as your like. (ReferenceTable) ESC monitors
the battery voltage at all times, the low voltage sets the threshold, the ESCis reduced to 40% of the power output,
lasts for 20 or 30 seconds and then completely cuts off the output. And the motor emits "Beep-Beep" and LED lights
flashin . Automatic
and reverse rotation, and
Value
e
BATTERY
I.Running Mode
2.Battery Type:
3.LowVoltage Cut-off
4.1nitial Start Force:
5.Maximum Forward Force:
6.Maximum Reverse Force:
7.Maximum Brake Force:
MOTOR
8.1nitial Brake Force:
9.1nitial DragBrake Force:
10.DragBrakeRate:
••• REALCAR
ON MODE 11.Neutral Range:
12.Start Mode / Punch:
7.4'/ 6.01' 8.W
13.FreewheeIing Function:
Underscore letter indicate factory default settings
Declaration of conformity:
For the products manufactured by Absima GmbH mentioned in this manual the compelling and relevant ECDirective will
apply:
Directive: 2004/108/EG
Declarationof conformity is ready for download under the following link:
http://wp.absima.com/en/index.php/downloads/erklaerungen/
The following special directives will apply. EN 61000-6-1:2007 EN61000-6-3:2007
This symbol on the products and / or accompanying documents means the used electrical and electronic products must be
at the end of their lifetime separatedfrom household waste. Pleasetake these products for the treatment, recovery and
recyclingto designated collection points, which will receivethe devicesfree of charge.The proper disposalof this product,
prevent any potential adverseeffects on humans and the environment which could otherwise arise from inappropriate
waste handling at the end of its lifetime. For more details of your nearest designated collection point, contact your local
authority. For businessusers in the European Union, pleasecontact your dealer or supplier for further information if you
wish to disposeelectrical and electronic equipment. He holds further information ready for you. Information on disposal in
other countries outside the European Union. This symbol is only valid in the European Union.
Absima GmbH,Gibitzenhofstrasse 127A, 90443 Nürnberg, Germany
Phone: +49 911 650841 30 Fax: +49 911 650841 40 E-Mail: info@absima.com
to next item to select.
-go to next value select.
-go to confirm your select.
-go back to factory setup.
Program Manual
shutdown after a roximatel two minutes
(2)
Forward/ Forward/ Forward/
Brake Reverse
Reverse/Brake
LiPo NiMH
3.11/ 2.911 3.21/ 3.4V Off
4% 6% 8%
100%
100%
100% 75% 50% 25%
100% 80% 60%
Level 5 Level4 Level3 Level2 Level 1
0.06ms 0.02ms 0.04ms 0.08ms 0.1ms
Level 3 Level 1 Level 2 Level 4 Level 5
Disabled Enabled
VALUE
aax
which
(7)
14%
Level 6
