As a result the following checks must be made in order to verify whether the position selected is correct:
- Check that there is sunlight present for most of the daytime at the selected installation location.
- Check that the installation location is not surrounded by thick vegetation or anything capable of creating shade.
- Check that the direction and angle of the solar panel are correct.
Warning: initially the battery charge will not be at the optimum level. It takes several days of
charging for your system to reach optimum capacity.
4

TECHNICAL SPECIFICATIONS

a. Control box:
- Rated voltage: 12V / 10A max
- Rated battery capacity: 18 Ah
- Operating temperature: -20°, +55°C
- Dimensions: 220 x 305 x 93 mm
5
OPTIONS
• Battery charger : CH UNIVERSAL 15
• Voltage converter : CONVERTY 150
6 MAINTENANCE
It is advisable to clean the panel regularly for optimum recharge capacity. The guarantee is void if parts have been
dismantled. Clean the outside with a soft dry cloth only.
Warning: Do not use any carboxylic acid or alcohol-based or other similar product or solvent. In addition to
the risk of damage to your device, fumes are also dangerous to health and are explosive.
For cleaning purposes do not use any tool that may act as a voltage conductor (e.g. metal brush or sharp tool) or
that could potentially scratch the glass.
Disposal of the battery: The battery contains pollutants and must not be thrown away in the household rubbish
after removing it from the installation. It must be disposed of or recycled by one of the methods provided for by
the legislation currently in force in your country.
7

TECHNICAL ASSISTANCE - GARANTEE

Fault
- No current supplied
- No current on the USB
outlet
GB ES
Cause
- Battery too low
- Faulty connection
- Reversed polarity
- Blown fuse
CFI EXTEL UNIVERSAL 15 - 08/2011 - V1
http://www.bakonline.net/
b. Photovoltaic solar panel
- Rated voltage: 18V
- Maximum power: 15W
- Operating temperature: -40°, +85°C
- Dimensions: 404 x 359 x 25 mm
- Weight: 2,20 kg
Solution
- Recharge the battery
- Check the connection (if necessary perform a
RESET)
- Check the wiring of the cigarette lighter
- Replace the fuse
