Wiring Configurations

Three configurations for connecting speakers to an amplifier
are Series, Parallel, and Series-Parallel wiring. A Series con-
figuration consists of two or more speakers wired in an string
(end to end). A Parallel configuration consists of two or more
speakers wired with the common terminals connected across
each other. A Series-Parallel configuration is a combination of
both methods. Determine which method will be compatible
with your amplifier.
R
T
• R
• R
• Red dot indicates "+" terminal of 8 ohm speaker
• Purple dot indicates "+" terminal of 4 ohm speaker
Downloaded from www.Manualslib.com
Series Wiring
= R + R + R + etc.
1 2 3
Series-Parallel Wiring
indicates the total speaker load
T
, R , etc. indicates each speaker in the system
1 2
manuals search engine
Parallel Wiring
1 1 1 1
= + +
R R R R
T 1 2 3
– 6 –
® ®
N
S
T
A
L
L
A
T
O
N
1
+ + etc.
R
4
I
I
