SYSTEM SETUp:
10
TRANSMITTER PROGRAMMING
Select a GROUP and/or CHANNEL:
Press the SET button (GROUP flashes). The desired frequency group is
selected using the arrow keys
button again (CHANNEL flashes). The desired frequency group is
selected using the arrow keys
input with SET.
1
Note: Any number of receivers can be used with one transmitter, provi-
ded all receivers are supposed to receive the same signal and are set to
the same radio frequency as the transmitter.
2
Audio input level display:
The audio input level is indicated by two bar indicators (channel left/
right, see Fig.
3
LC display options:
Audio input level, transmitter radio frequency (see Figure
Adjust the audio input level using the level controls on the rear panel
of the transmitter. Higher input levels result in improved signal to noise
ratio. The input stage must not be overloaded.
4
and (see Figure
and (see Figure
3
).
1
). Press the SET
2
). Confirm the
4
).
