Operating instructions
USB-MIDI-Cable
Item no. 1656343
Intended use
The product is used to connect a MIDI device (e.g. a keyboard) to the USB port of a computer.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in
bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can cause hazards. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• USB-MIDI-cable
• Operating instructions
Features
• Cable length 2 m
• Plugs for "MIDI-in" and "MIDI-out"
• A driver is not required (since it is integrated in Windows XP/Vista)
Latest operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code shown. Follow the instructions on the website.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
Connection
• Connect the "MIDI-out" plug of the cable with the "MIDI-in" plug of your MIDI device
(e.g. a keyboard).
• Connect the "MIDI-in" plug of the cable with the "MIDI-out" plug of your MIDI device
(e.g. a keyboard).
• Then connect the USB plug of the cable to a free USB 2.0/1.1 port on your computer.
• The power LED at the MIDI-USB-cable will illuminate, Windows will recognize the new
hardware and install the drivers (included in XP/Vista).
Tips & notes
• There is no MIDI-Software included in the product contents of the USB-MIDI-cable. Please
purchase the software separately. Choose the correct USB audio device within the software
and follow the software's operating instructions.
• On the USB-MIDI-cable there is one LED available for each "MIDI-in" and "MIDI-out". These
display the transfer of data.
• The power for the electronics of the USB-MIDI-cable is supplied via USB.
• Please make sure that MIDI plugs of the USB-MIDI-cable are allocated correctly to MIDI
sockets of you MIDI device, see "Connection". If the connections are interchanged a transfer
of data will not be possible.
• Also, do not interrupt the connection of the computer and the MIDI device during running data
transfer. You risk crashing not only the MIDI software but the operating system, too.
• Always connect the USB plug to the same USB port of your computer, otherwise the driver
might be installed again.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE. *1656343_V1_0318_02_mxs_m_en
