INSTRUCTION MANUAL
Blade replacement
Open the blade guard (11) fully and secure it in
the open position using a screwdriver or a piece
of wood.
Secure the blade to prevent it turning during
replacement by inserting a screwdriver or similar
item through one of the holes in the blade.
Undo the lock bolt (13) by turning it anticlockwise.
Remove the lock bolt and outer flange (12) and
then the blade. Do not dispose of the old blade
in your domestic refuse. Dispose of it correctly in
accordance with local guidelines.
Remove any chips or sawdust from around the
spindle and flanges.
Fit the new blade, outer flange and lock bolt.
Be sure to fit the blade correctly with regard to
direction of rotation – see the markings on the
blade.
Check that the blade touches the flanges when
replaced. Tighten the lock bolt, but do not over-
tighten.
Take hold of the blade guard and remove the tool
or piece of wood holding the guard open. Check
to ensure that the blade guard works correctly.
ENGLISH
Cleaning and maintenance
To clean the saw, wipe its external parts with a
damp cloth.
From time to time lubricate moving parts with oil.
Environmental information
You can help protect the environment!
Follow local environmental regulations:
Dispose of unwanted electrical
equipment at an approved recycling
station.
17
