SAFETY NOTES
1.Children should always wear a helmet and protective gear, including elbow pads, knee pads, and hand guards.
2. The balance bike is intended for use only in safe, designated areas such as pavements, playgrounds, and paths.
3. The maximum load capacity of the product is 25 kg. Exceeding this weight may result in damage or accidents.
4. The balance bike must be assembled by an adult in accordance with the instructions.
5. Ensure that all parts are properly secured and that all locks are fastened.
6. Children should not use the bike without adult supervision.
7. Before use, teach your child the rules of safe riding and stopping.
8. The bike should only be used on smooth, even surfaces, free from sand, gravel, water, or other obstacles.
9. Avoid using the bike near swimming pools, stairs, steep slopes, or in the vicinity of small children.
10. Ensure that your child's clothing and accessories do not restrict their vision, hearing, or freedom of movement.
11. Only one child may use the bike at a time.
12. While riding, do not push or shove a child sitting on the bicycle.
13. Before starting to play, check that there are no hazards nearby that could cause an accident.
14. Do not leave the bike outside overnight to avoid damage and reduce risk to other children.
LIST OF PARTS
1.
Rear wheel
2.
Front wheel
3.
Saddle
4.
Screw
5.
Handlebar
6.
Triangular cap
7.
Latch
8. Tools
9.
Plastic seal
10. Gasket
ASSEMBLY
Step 1:
a)
Insert the front fork into the main frame.
b)
Fit the washers and the lock, ensuring that the washer is positioned under the lock.
Step 2:
a)
Insert the locking cover sleeve through the handlebar tube.
b)
Insert the handlebar tube into the front fork, adjust the angle of the front wheel and handlebar as required. Then secure the clamp in
place with a spanner.
c) Finally, replace the locking cover. To adjust the height, loosen the fixing screw, set the desired position, and then tighten the screw
again after adjustment.
Step 3:
a)
Insert the shaft into the rear tyre and tighten the spacer.
b)
After inserting the spacer shaft, install it simultaneously in the main frame as shown in the figure.
c)
Secure the spacer gasket in the main frame hole and fasten with nuts.
d)
First, turn the nuts on the left and right sides by hand, then tighten them with a spanner.
Step 4:
a)
Pull the cover over the seat cushion tube.
b)
Insert the seat cushion tube into the main frame, adjust the angle of the seat cushion and main frame as needed, and then secure the
clamp in place using a spanner.
c)
Replace the lock cover. To adjust the height, loosen the fixing screw, set the desired position, and then tighten the screw again.
Note: When adjusting the height of the handlebar or saddle, do not lower them below the indicator line.
Ensure that the protruding part of the screw fits correctly into the concave part of the clamp.
