DEC-38D DUAL COUPLER
Ø38/50mm
Item 59006960
For your own safety, please read this leaflet carefully before
you initially start-up. You can find the latest update online.
SAFETY INSTRUCTIONS
This product has left our premises in absolutely perfect
condition. In order to maintain this condition and to ensure
a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in
this user manual. Damages caused by the disregard of this
user manual are not subject to warranty. The dealer will not
accept liability for any resulting defects or problems. If the
product will be operated in any way different to the one
described in this manual, it may suffer damages and the
guarantee becomes void. Furthermore, any other operation
may lead to dangers like crash etc. Please consider that
unauthorized modifications on the adapter are forbidden
due to safety reasons.
OPERATING DETERMINATIONS
This dual coupler is designed for installing projectors,
lighting effects and other devices. The coupler can be used
for tubes with a diameter of 38 mm or 50 mm. The
maximum load of 50 kg horizontally and 25 kg vertically
must never be exceeded. This product is designed for
professional use, e.g. on stages, in discotheques, theaters
etc. Make sure that the area below the installation place is
blocked when rigging, derigging or servicing.
INSTALLATION INSTRUCTIONS
Please consider the DIN 15560-27 and the respective
national norms during the installation! The installation must
only be carried out by an authorized dealer! Before taking
into operation for the first time, the installation
has to be approved by an expert.
The installation of the device has to be built and constructed
in a way that it can hold 10 times the weight for 1 hour
without any harming deformation.
The installation must always be secured with a secondary
safety attachment, e.g. an appropriate catch net. This
secondary safety attachment must be constructed in a way
that no part of the installation can fall down if the main
attachment fails.
When rigging, derigging or servicing the device staying in
the area below the installation place, on bridges, under high
working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and
machine-technical installations are approved:
• by an expert before taking into operation for the first time
and after changes before taking into operation another
time.
• by an expert after every four year in the course of an
acceptance test.
• by a skilled person once a year.
The device should be installed outside areas where persons
may walk by or be seated. The device has to be installed
out of the reach of people.
www.eurolite.de
Overhead rigging requires extensive experience, including
(but not limited to) calculating working load limits, installation
material being used, and periodic safety inspection of all
installation material and the device. If you lack these
qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper
installation can result in bodily injury and or damage to
property.
If the device shall be lowered from the ceiling or high joists,
professional trussing systems have to be used. The device
must never be fixed swinging freely in the room.
Devices in hanging installations may cause severe injuries
when crashing down! If you have doubts concerning the
safety of a possible installation, do not install the device!
Before rigging make sure that the installation area can hold
a minimum point load of 10 times the device's weight.
Mount the device to your truss system via the clamp. For
overhead use, always install an appropriate safety bond.
You must only use safety bonds complying with DIN 56927,
quick links complying with DIN 56926, shackles complying
with DIN EN 1677-1 and BGV C1 carbines. The safety
bonds, quick links, shackles and the carbines must be
sufficiently dimensioned and used correctly in accordance
with the latest industrial safety regulations (e. g. BGV C1,
BGI 810-3).
Pull the safety bond through the attachment eyelet and over
the truss system or a safe fixation spot. Insert the end in the
quick link and tighten the safety screw. The maximum drop
distance must never exceed 20 cm. A safety rope which
already hold the strain of a crash or which is defective must
not be used again.
TECNICAL SPECIFICATIONS
Max. load: ................... 50 kg (horizontally)
Max. load: ................... 25 kg (vertically)
Thread: ....................... M10 x 30 mm
Dimensions (LxWxH): . 108 x 90 x 48 mm
Weight: ........................ 0.21 kg
Classification: .............. UL94, 3 mm
.................................... IEC/DIN EN 60695-11-10/-20
Every information is subject to change without prior
notice. 15.10.2014 ©
00081024.DOCX, Version 1.1
