Pin Assignment; Connection Example - Carson Reflex Switch 2/4 Bedienungsanleitung

pin aSSignment

connection example

Distribution terminal with fuse
16V max.
RC receiver
To speed controller
To speed controller
Switch module
Positive
terminal
Negative terminal
Instruction Manual // GB
