Plug actuator SES FS-ZW
6. Disposal
Packaging and replaced parts are to be
disposed of in accordance with the regula-
tions of the country in which the device was
installed. Do not dispose of the extender
with household waste; instead, take it to
your local authorised collection point.
7. Warranty
Please contact your local dealer for information an cus-
tomer service and warranty conditions.
EN-6
8. Technical data
Operating voltage
Switching power
Switching current
Continuous power
Continuous
current
Energy consump-
tion
Wireless
technology
Range
Relay
Power measure-
ment
Energy measure-
ment
Protection class
Ambient tempera-
ture
Dimensions
Weight
Certifications
Subject to technical alterations
SES FS-ZW_en · 05/15/B
230 V +15 % / –10%; 50 Hz
max. 3680 W resistive
max. 16 A
max. 3200 W resistive
max. 14 A
0,75 W typical ; 1,2 W maximum
Z-wave (868 MHz EU frequency)
Typical 20 m in buildings; actual
range will depend
on specific conditions in the building
Approx. 100 m outdoors
Switching relay approved for lamp
loads (inrush
current) and inductive loads
0 ... 3680 W; Measurement
resolution 0.1 W
Display resolution 1 W
Measurement resolution 0.1 Wh
Display resolution 1 Wh
IP 20
0 ... 35 °C
113 x 56 x 70 mm (H x W x D)
132 g
VDE, CE, Z-Wave
