GB | LED Solar Light
Do not connect the chain to power supply if it is
in packaging.
Light sources are not replaceable.
Do not connect another light.
When handling, disconnect from the power
network.
In case of malfunction, do not remove bulbs and
do not repair the chain!
Do not interfere with the connection.
WARNING – THIS LIGHT CHAIN MUST NOT BE USED WITHOUT THE APPROPRIATE GASKETS!
WARNING – RISK OF INJURY BY ELECTRICAL CURRENT! DO NOT USE WITH MISSING OR DAMAGED
LIGHT SOURCES!
Three position switch function:
OFF – constantly off
TIMER – the product lights up in repeated cycles daily for 6 hours, then turns off for 18 hours
ON – constantly on
Technical specifications:
Battery: 1× Ni-MH AA – 1.2 V DC 600 mAh
Product power: 2.4 W
Protection type: IP44
Duration of illumination: max. 10 h with a fully charged accumulator
Number of LEDs: 120 pcs
Operation:
The panel can be switched on and off by pressing the ON/OFF (POWER) button.
Press the 'timer' button to activate the timer function. The light chain will flash shortly to confirm
that the timer is activated.
Press the 'timer' button again to de-activate the timer function.
Solar panel must be installed in a well-lit place where it can receive the maximum sunlight during
the day. Any sunshade on the panel will reduce it's ability to absorb sunlight and reduce the bright-
ness and duration of LED lamps. Solar panels should not be in a place where they can be affected
by rain or snow. This string of lights can be hung on branches, bushes, roofs, eaves, fences or any
other place you want.
The solar panel box can be placed on the ground by using the ground plug base. The base should be
fixed in the ground until it is stable. Please make sure that the solar panels are facing up to the sun.
Lighting requires at least 6 hours of sunlight.
Although solar panels will continue to collect energy on cloudy days, rainy days or snow, it will reduce
the ability to accumulate energy and the duration of lighting. For example, sunny days can provide
at least 3–4 hours of lighting, while rainy or snowy days can only provide 1–2 hours of lighting.
Use only with the power source supplied with
the product.
Suited for both indoor and outdoor use.
Should the light source rupture or become
damaged, do not use the light chain or leave it
connected to the power supply. Instead, dispose
of it in a safe, environment-friendly way.
The product is designed for decorative lighting.
The product is not a toy; do not put it in the hands
of children!
1. Solar panel with lamp string attached – 1 PC
2. Rod – 1 PC
3. Ground plug base – 1 PC
