A
B
C
D
G
12 12
E
I
Fig. 3.1
3 DESCRIPTION
The connection box is supplied with all
equipment
compatible Palazzetti pellet stove.
Description of main components and assemblies
A. Articulated antenna
F
B. Reset button
C. Power socket
D. Ethernet cable socket
E. Status led
F. RJ11 socket
G. USB port
H. Splitter
I.
J. Power supply
H
J
required for
Power plug
connection to a
