Contents of package
6 5* 4*
1
2 3*
1. Connection box
2. Power supply
3. RJ11 male/male cable
(*only packages not supplied as standard equipment with the stove)
4. RJ11 male / MODU2 4pin female cable
(*only packages not supplied as standard equipment with the
stove)
5. RJ11 triple female splitter
(*only packages not supplied as standard equipment with the stove)
6. Velcro
f= female
m= male
