Fig. 1.
Technische Daten / Specifications / Spécifications / Specifiche / Datos técnicos / Technische gegevens / Tekniske data / Tekniska
data / Technická data / Dane techniczne
Connectors
Input
Battery
Charging time
Working time
Environmental conditions
Emission sound pressure level LpA/LwA
Uncertainty KpA/KwA
Vibration level (a
Uncertainty K (According to
EN 62841-2-2:2014)
No-load speed n
Max. torque
Dimensions | Weight
Flat slot (3-7 mm)
Cross recess (PZ0-3, PH0-3)
Hexagon (H3-H5)
6-point star (T10-T25)
50 mm flat slot 5 mm/cross recess PZ2
Bit extension (length 60 mm)
Connectors | Cable length
Verwendete Symbole / Symbols used / Symboles utilisés / Simboli utilizzati / Símbolos utilizados / Gebruikte symbolen / Brugte symboler / Använda symboler
/ Použité symboly / Stosowane symbole
V1.0alw V1.0alw Änderungen und Irrtümer vorbehalten.
)
h
0
Direct current
USB-C™ socket
5.0 V
Li-Ion, 4.0 V, 1500 mAh
2-3 hrs
max. ~45 Min.
-5~+40 °C, max. 95 % RH
55.5 / 66.5 dB(A)
3.0 dB(A)
< 0.912 m/s²
1.5 m/s²
200
8 Nm
approx. 153 x 44 x 115 mm | approx. 364 g (device only)
Bits
USB cable
USB-A, USB-C™ | 1.5 m
Goobay® by Wentronic GmbH | Pillmannstraße 12 Goobay® by Wentronic GmbH | Pillmannstraße 12
- 1 -
38112 Braunschweig | Germany | cs@wentronic.com 38112 Braunschweig | Germany | cs@wentronic.com
77817 77817
, 1000 mA
-1
5x
14x
3x
4x
2x
1x
IEC 60417- 5031
