ASSEMBLY

1. Plug the telescopic rod (2) into the re­
cess on the top of the motor unit (5).
2. Place the hanger (1) onto the telescopic
rod (2). When you do this, make sure
that the slight bend in the hanger (1)
points forwards.
3. Check that the drip protection (3) is fit­
ted securely on the telescopic rod. The
drip protection must be fitted approx.
15 cm above the fan outlet. It prevents
any water that may drip down from
being able to get into the fan (4). Make
sure that the drip protection is not fitted
any lower to prevent a build­up of heat
in the fan.
4. Attach the balloon:
○ Pull it over the hanger (1). When you
do this, make sure that the side with
the hole line points forwards.
○ Pull the small elastic cord at the top
over the collar section (10) on the
hanger (1).
○ Pull the large elastic cord at the bot­
tom over the mounting flange (8).
The device is disassembled in the reverse
order.

USE

Please note!
■
Only connect the device to a plug
socket that is properly installed. The
plug socket must also be readily ac­
cessible after connection so that the
connection to the mains can quickly be
isolated. The mains voltage must match
the rating plate of the device.
■
Do not connect the device along with
other consumers (with a high wattage)
to a multiple socket in order to prevent
overloading and a possible short circuit
(fire).
■
Do not use any extension cables more
than 3 m long or cable extension reels.
■
Always switch off the device first before
the plug is pulled out of the plug socket.
One exception is when the device has
fallen into water or in the event of a fault.
■
Always place the device with clear space
above it and on all sides on a dry, flat,
solid and heat­resistant surface.
■
It is essential that you follow the care
labels for the textiles to be dried!
1. Set the height you want. To do this,
open the clip (9), pull out the telescopic
rod (2) and then close the clip (9) again.
2. If you have not already done so, pull on
the balloon (see the chapter "Assem­
bly").
L
The balloon should sit immediately
below the mounting flange (8) so
that it can fully inflate.
3. Pull the garment which is to be pressed
over the balloon and the hanger (1) and
do up the buttons if necessary. Make
sure that
○ the collar is fitted over the collar sec­
tion (10) on the hanger (1),
