RECLINE
1
There are three recline positions.
2 To lower or raise the recline, pull up on the top of the
seat to release the connection (1). Then press in on the
recline adjustment button (2) and adjust the seat to
the desired recline position. A "click" sound means the
recline position is engaged.
SEAT COVER
3
Open the zipper at the bottom of the seat.
4 Unfasten the button at the bottom of the seat to remove
the softgoods.
Reverse the operation to install the softgoods, Please
wrap the seat tube inside the softgoods before
installation.
BASE
5 To remove the seat from the base, insert a flat head
screwdriver into the slot on the back of the seat mount,
and press to disengage the connection.
Once the connection is disengaged, slide the seat off
the base mount.
DO NOT detach the seat from the base by any other
method.
12 SHELL
™
1
2
1
2
click
3
4
5
