Assemble and disassemble the battery pack on the handheld vacuum
Assemble the battery pack: align the battery pack with the guiding slot on the handheld
vacuum body, slide it in the direction of the arrow shown. Afterwards, pull the battery pack after
installation to ensure it is fit in position.
Attention: when the vacuum cleaner is not used for a long time, remove the battery, pack the
machine, and store it in a cool and dry place. Avoid direct sunlight or a humid environment.
Battery pack
release button
Assemble and disassemble the metal tube
1. As shown in the picture, align the conductive needle of the metal tube with the handheld
vacuum coupler, then push the handheld vacuum downward until a "click" sound is heard.
2. To disassemble the handheld vacuum, please press the metal tube release button, and pull
up the handheld vacuum simultaneously to remove it.
Metal tube release
button
Assemble and disassemble the wet polishing head [JV10 Pro Aqua only]
1. Hold the wet polishing head and plug the metal tube into the connector of the wet polishing
head in the direction shown in the picture.
2. Then, align the conductive needle with the coupler and push it downward to the metal tube
until a "click" sound is heard.
Wet polishing
head release
button
